Disc brake caliper DS 280 FEAspring activatedelectro-hydraulic release
Add to favorites
Compare this product
Characteristics
- Type
- disc
- Operation
- spring activated, electro-hydraulic release
- Torque
Max.: 8,100 Nm
(5,974.253409 ft.lb)Min.: 1,200 Nm
(885.074579 ft.lb)- Braking force
10,050 N, 12,250 N, 20,050 N, 33,250 N
- Power
240 W, 280 W, 370 W, 590 W
Description
Product overview
Available downloads (names only)
Features (table)
Features | Code
Brake Caliper | D
Disc Brake | S
Frame size | 280
Spring activated | F
Electrohydraulically released | E
Automatic adjustment to counter friction block wear | A
Thrustors | 453 to 456
Thrustor mounted | R / L
Thickness of brake disc | 30 mm
Technical specifications
- Spring-activated, electrohydraulically released disc brake caliper DS 280 FEA
- Automatic adjustment to compensate friction block wear
- Thrustors available: types 453–456; mounting right or left
- Designed for brake disc thickness: 30 mm
Available downloads (names only)
- Datasheet DS 280 FEA (PDF)
- Flyer Disc Brake DS (PDF)
- 3D CAD models (STEP)
- Installation instructions DS XXX FEM-FEA (PDF)
- Catalogue Industrial Brakes (PDF)
Features (table)
Features | Code
Brake Caliper | D
Disc Brake | S
Frame size | 280
Spring activated | F
Electrohydraulically released | E
Automatic adjustment to counter friction block wear | A
Thrustors | 453 to 456
Thrustor mounted | R / L
Thickness of brake disc | 30 mm
Technical specifications
- Product type: brake caliper / disc brake, spring-activated, electrohydraulically released
- Frame size: 280
- Codes: D (Brake Caliper), S (Disc Brake), F (Spring activated), E (Electrohydraulically released), A (Automatic adjustment)
- Thrustors: 453, 454, 455, 456 (selectable)
- Thrustor mounting: Right (R) or Left (L)
- Brake disc thickness: 30 mm
