Disc brake caliper DS 370 FEA

spring activatedelectro-hydraulic release

Product overview

• Spring-activated, electrohydraulically released disc brake caliper designed for frame size 370.
• Automatic adjustment compensates for friction block wear to maintain braking clearance.
• Selectable thrustors: 455, 456 or 457; thrustor can be mounted on right or left side.
• Recommended brake disc thickness: 30 mm.

Documents & downloads

• Datasheet DS 370 FEA
• Disc Brake DS flyer
• 3D CAD models (STEP / ZIP)
• Installation instructions DS XXX FEM-FEA
• Industrial brakes catalog

Features (table)
Features | Code
Brake caliper | D
Disc brake | S
Frame size 370 | 370
Spring-activated | F
Electrohydraulically released | E
Automatic adjustment to counter friction block wear | A
Thrustors available | 455 / 456 / 457
Thrustor mounted right or left | R / L
Thickness of brake disc | 30 mm

Technical specifications

• Model: DS 370 FEA
• Product type: Disc brake caliper
• Frame size: 370
• Activation: Spring-activated (F)
• Release: Electrohydraulically released (E)
• Automatic adjustment: Yes (A)
• Compatible thrustors: 455, 456, 457
• Thrustor mounting: Right (R) or Left (L)
• Recommended brake disc thickness: 30 mm
