Disc brake caliper DS 230 FEM
caliper discmanualspring activated

Disc brake caliper - DS 230 FEM - RINGSPANN - caliper disc / manual / spring activated
Disc brake caliper - DS 230 FEM - RINGSPANN - caliper disc / manual / spring activated
Add to favorites
Compare this product
Go to the RINGSPANN website for more information

Characteristics

Type
disc, caliper disc
Operation
spring activated, manual, electro-hydraulic release
Other characteristics
for heavy-duty applications

Description

Product overview
The DS 230 FEM is a spring-activated, electrohydraulically released brake caliper designed for industrial disc brake applications. Frame size 230 for brake disc thickness 30 mm. Manual wear adjustment compensates friction block wear. Compatible thrustors: 451, 452, 453, 454. Thrustor can be mounted on the right or left side. Suitable for industrial machinery and heavy-duty brake systems.

Files
  • Datasheet DS 230 FEM
  • Disc Brake flyer DS
  • 3D CAD models (STEP / ZIP)
  • Installation instructions DS XXX FEM-FEA
  • Industrial Brakes catalogue

Features (table)
Features | Code
Brake Caliper | D
Disc Brake | S
Frame size 230 | 230
Spring activated | F
Electrohydraulically released | E
Manual wear adjustment | M
Thrustors available 451–454 | 451–454
Thrustor mounting right or left | R / L
Brake disc thickness 30 mm | 30

Characteristics / technical specifications
  • Product type: Brake caliper (disc brake)
  • Series / model: DS 230 FEM
  • Frame size: 230
  • Operation: Spring-activated, electrohydraulically released
  • Manual wear adjustment: Yes
  • Compatible thrustors: 451, 452, 453, 454
  • Thrustor mounting: Right or left
  • Brake disc thickness: 30 mm
  • Available resources: Datasheet, product flyer, 3D CAD (STEP/ZIP), installation instructions, catalogue
