Rotary damper TBGfluidfor the automotive industryone-way
Add to favorites
Compare this product
Characteristics
- Function
- rotary
- Technology
- fluid
- Applications
- for the automotive industry
- Other characteristics
- one-way
- Diameter
Min.: 6.6 mm
(0.3 in)Max.: 12.8 mm
(0.5 in)- Thread diameter
15 mm
(0.6 in)- Height
2.1 mm
(0.1 in)
Description
Description
Rotary one-way dampers TBG are designed to control the opening stroke of doors and panels in industrial applications. Available across a range of torque ratings, these dampers are also used in timing and radial-movement mechanisms where controlled, unidirectional deceleration is required. The design focuses on consistent torque and precise movement for integration into assemblies.
Technical references (table)
Reference | No. Teeth (Z) | Pitch diameter Dp | h / H | D | A | Panel thickness c
50002000112 | 10 | 8,00 | 3,50 / 8,50 | 14,95 | 20,80 | 2,10
50002000113 | 11 | 6,60 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000111 | 11 | 8,80 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000114 | 11 | 8,80 | 4,50 / 9,50 | 14,95 | 20,80 | 2,10
50002000115 | 11 | 8,80 | 5,00 (3+2) / 10,00 | 14,95 | 20,80 | 2,10
50002000117 | 12 | 9,60 | 3,50 / 8,00 | 14,95 | 20,80 | 2,10
50002000116 | 12 | 9,60 | 3,50 / 8,50 | 14,95 | 20,80 | 2,10
50002000118 | 13 | 10,40 | 5,00 / 10,00 | 14,95 | 20,80 | 2,10
50002000119 | 14 | 7,00 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000120 | 16 | 12,80 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000121 | 16 | 12,80 | 5,00 / 10,00 | 14,95 | 20,80 | 2,10
Notes
Drawing PDF: available via the product page (site-triggered). RoHS: compliant. Measures expressed in: Millimeters. UL94: not applicable / no classification indicated. IP: not indicated.
Features / technical specifications
Rotary one-way dampers TBG are designed to control the opening stroke of doors and panels in industrial applications. Available across a range of torque ratings, these dampers are also used in timing and radial-movement mechanisms where controlled, unidirectional deceleration is required. The design focuses on consistent torque and precise movement for integration into assemblies.
Technical references (table)
Reference | No. Teeth (Z) | Pitch diameter Dp | h / H | D | A | Panel thickness c
50002000112 | 10 | 8,00 | 3,50 / 8,50 | 14,95 | 20,80 | 2,10
50002000113 | 11 | 6,60 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000111 | 11 | 8,80 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000114 | 11 | 8,80 | 4,50 / 9,50 | 14,95 | 20,80 | 2,10
50002000115 | 11 | 8,80 | 5,00 (3+2) / 10,00 | 14,95 | 20,80 | 2,10
50002000117 | 12 | 9,60 | 3,50 / 8,00 | 14,95 | 20,80 | 2,10
50002000116 | 12 | 9,60 | 3,50 / 8,50 | 14,95 | 20,80 | 2,10
50002000118 | 13 | 10,40 | 5,00 / 10,00 | 14,95 | 20,80 | 2,10
50002000119 | 14 | 7,00 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000120 | 16 | 12,80 | 3,00 / 8,00 | 14,95 | 20,80 | 2,10
50002000121 | 16 | 12,80 | 5,00 / 10,00 | 14,95 | 20,80 | 2,10
Notes
Drawing PDF: available via the product page (site-triggered). RoHS: compliant. Measures expressed in: Millimeters. UL94: not applicable / no classification indicated. IP: not indicated.
Features / technical specifications
- Brand: ISC Plastic Parts
- Commercial denomination (model): TBG
- Product type: Rotary damper one-way
- Compliance: RoHS compliant
- Measurement unit: Millimeters
- Video available for this product (hosted on site)
- Number of available references / variants shown: 11 (see table above)
