Threaded knob MVCH

roundPOMfor the automotive industry

Product description
The MVCH hexagonal head knob is manufactured in POM and designed for metric threaded fastenings. Available in several colours and supplied in multiple thread sizes. Good surface finish suitable for industrial applications.

Downloads and certifications
Drawing PDF: Available
UL94: Not available
IP: Not available
RoHS: Compliant
Measures expressed in: Millimeters
Video: Available

Available references
Reference — Suitable for — A — B — C
00100101000 — M3 — 9.53 — 5.16 — 8.33
00100101005 — M4 — 12.70 — 5.56 — 9.53
00100101011 — M5 — 16.60 — 6.35 — 10.72
00100100999 — M6 — 19.05 — 7.93 — 12.70
00100101017 — M6 — 25.40 — 8.33 — 12.70
00100101028 — M8 — 25.80 — 10.15 — 15.20

Related families and materials information

• Related families: MWD (flowerette knobs), MWC (wing head knobs), TU washers, TI flanged washers.
• Materials and properties (examples from related items): LDPE — up to 70 °C, flexible and insulating; PA6 — up to 100 °C, good strength and thermal balance; PA66 — increased rigidity and dimensional stability; PA6GF30 — 30% glass-fibre reinforced, higher stiffness and heat resistance up to 130 °C.

Technical characteristics / specifications

• Model: MVCH
• Material: POM (polyoxymethylene)
• Head type: Hexagonal
• Finish: Good surface finish
• Colours: Various available
• RoHS: Compliant
• UL94: Not specified / not applicable
• IP rating: Not specified
• Measures expressed in: Millimeters
• Available thread sizes and main dimensions: M3, M4, M5, M6, M8 (see table above)
