Immersion circulator PRO P 2 EC

Product description
The PRO P 2 EC circulating and process thermostat is designed for external applications up to 250 °C. Its low filling volume enables fast temperature ramp-up in the connected system. The compact tower design saves installation space. An integrated cooling coil and hybrid refrigeration allow cooling by ambient air and, when required, by cooling water. All units are equipped with a pressure/suction pump for reliable fluid circulation.

Features

• Microprocessor-controlled thermostatic circulator with integrated cooling coil
• Detachable command console usable as remote control
• Timer and count-down functions
• SelfCheck Assistant for system diagnosis
• Fully electronic continuous PID controller for internal and external control
• Tower design with small footprint
• Stainless-steel bath vessel, insulated, with overflow and drain tap
• Large 5.7" multi-touch color display
• User administration for up to 20 users
• EasyUse system for simplified operation of the unit
• USB and Ethernet interfaces fitted as standard
• PowerAdapt system to maximise available heating power without overloading supply
• LAUDA Varioflex pump (pressure/suction) with 8 selectable levels, rear connections
• Data entry and operation via multi-touch display
• Data import/export via USB
• Low-level and adjustable over-temperature protection with acoustic alarm for flammable and non-flammable liquids
• Retrofittable interfaces: RS232/485, Profibus, EtherCAT, analogue or contact modules
• Programmer with up to 100 programs, up to 50 segments each
• Very low filling volume for rapid temperature changes

Working range
Min. working temperature: 80 °C
Max. working temperature: 250 °C
Temperature stability: 0.05 ± K

Technical data (according to DIN 12876)

• Working temperature range: 80 ... 250 °C
• Working temperature range with water cooling: 20 ... 250 °C
• Operating temperature range: -30 ... 250 °C
• Ambient temperature range: 5 ... 40 °C
• Temperature stability: 0.05 ± K
• Heater power max.: 2.5 kW
• Max. power consumption: 2.7 kW
• Current consumption: 12 A
• Max. discharge pressure: 0.7 bar
• Max. pump suction: 0.4 bar
• Max. pump flow (pressure): 22 L/min
• In/Outlet connection thread (outside): M16 x 1
• In/Outlet Ø olives: 13 mm
• Min. filling volume: 2.4 L
• Max. filling volume: 4.4 L
• Dimensions (W x D x H): 250 x 365 x 425 mm
• Weight: 17 kg
• Power supply: 200-230 V; 50/60 Hz
• Power plug: Power cord with angled plug (CEE7/7)
• Part number: L000020

Technical specifications

• Model: PRO P 2 EC
• Working temperature range: 80–250 °C (20–250 °C with water cooling)
• Temperature stability: 0.05 ± K
• Heater power (max): 2.5 kW
• Max. pump flow: 22 L/min
• Filling volume: min. 2.4 L / max. 4.4 L
• Connections: M16 x 1 / Ø 13 mm olives
• Dimensions (W x D x H): 250 x 365 x 425 mm
• Weight: 17 kg
• Power supply: 200-230 V; 50/60 Hz; power cord with angled plug (CEE7/7)
