High temperature heating circulator Universa U 12 E

Product description
The Universa U 12 E bath circulation thermostat is a modular temperature control unit for liquid baths with nominal bath volumes of approx. 10.8–14.3 L and heating outputs within the Universa range (2–3.6 kW). It is intended for standard industrial temperature control tasks up to 100 °C and provides flexible connectivity and interchangeable components.

Features

• Bath circulation thermostat for standard temperature control tasks up to 100 °C with intuitive 3‑button operation and bright VA LC two‑line display.
• Circulation pump with flow reduction for adjustable volume flow and constant pressure (max. 15 L/min; max. discharge pressure 0.2 bar).
• Integrated Ethernet and USB interfaces plus WLAN for local network and device communication (Wi‑Fi use restricted to certified countries/regions).
• Modular construction: interchangeable control head and heating/cooling base for flexible adaptation to current and future requirements.
• Integrated timer with countdown for time‑controlled processes.
• Remote access via integrated web server, LAUDA Command app and LAUDA.LIVE cloud connectivity (PKI and 2‑factor authentication supported).
• Safety functions including low‑level and overtemperature protection with audible and visual alarms for operation with non‑flammable liquids.

Working range
Min. working temperature: 35 °C
Max. working temperature: 100 °C
Temperature stability: 0.05 ± K

Technical data (according to DIN 12876)
Working temperature range: 35 ... 100 °C
Working temperature range with water cooling: 20 ... 100 °C
Operating temperature range: -30 ... 100 °C
Ambient temperature range: 5 ... 40 °C
Temperature stability: 0.05 ± K
Max. power consumption: 2.4 kW
Current consumption: 10 A
Bath opening (WxD): 200 x 200 mm
Min. / max. bath volume: 10.8 / 14.3 L
Max. discharge pressure: 0.2 bar
Max. pump flow: 15 L/min
Dimensions (WxDxH): 280 x 450 x 450 mm
Weight: 12 kg
Power supply: 200-240 V, 50/60 Hz
Power plug: Power cord with angled plug (CEE7/7)

Characteristics / technical specifications

• Device line: Universa (modular control head + heating/cooling base)
• Model: U 12 E
• Bath volume (variant shown): approx. 10.8–14.3 L (device family: 4–40 L)
• Heating output (product family): 2 kW – 3.6 kW
• Temperature stability: 0.05 ± K
• Pump: max. flow 15 L/min; max. discharge pressure 0.2 bar
• Connectivity: Ethernet, USB, integrated Wi‑Fi, web server; LAUDA Command app and LAUDA.LIVE compatibility
• Dimensions & weight: 280 x 450 x 450 mm; 12 kg
