Electric cut-off saw iqiege®130D

for metals

Overview
The IQIEGE 130D is an entry-level metallographic sample cutting machine designed for rapid sectioning of small metal specimens. It uses a high-speed rotary thin-slice cutting wheel and a forced cooling system to reduce heat build-up during cutting, minimising thermal alteration of specimen microstructure. The unit is compact, straightforward to operate and intended for routine laboratory use in industrial, research and academic environments.

Main Technical Specifications (table)
Maximum cutting cross-section: 30×30 mm
Cutting disc: Φ250×2×32 mm
Spindle speed: 2,800 rpm
Motor power: 1.1 kW
Input power: Three-phase AC 380 V, 50 Hz
External dimensions: 650 mm × 450 mm × 400 mm
Net weight: 60 kg

Product details and characteristics

• Model: IQIEGE 130D (entry-level metallographic cutter)
• Cutting method: high-speed rotary thin-slice cutting wheel for metallographic specimens
• Intended materials: designed for cutting relatively hard metallic materials
• Cooling: dedicated forced-cooling system to dissipate heat and prevent thermal damage to specimen microstructure
• Cutting capacity: up to 30 mm (maximum) / cross-section 30×30 mm
• Cutting disc specification: Φ250×2×32 mm
• Spindle speed: 2,800 rpm
• Drive: 1.1 kW motor
• Control: fully manual lever control
• Power supply: Three-phase AC 380 V, 50 Hz
• Design: compact, space-saving footprint suitable for routine laboratories and teaching facilities
• Recommended for: factories, research institutes and university laboratories
