Stone polishing machine iqiege 10

for specimen preparationindustrialcutting

Product overview
This model is designed for cutting and polishing rock samples to prepare specimens for petrographic observation. It features separate cutting and grinding chambers with a coolant circulation system that removes heat generated during cutting to prevent thermal damage to sample microstructure. The unit is easy to operate and reliable, suitable for industrial production sites, research institutes and university laboratories.

Detailed specifications
Model: iqiege 10
Supply voltage / frequency: Single-phase AC 220V 50Hz
Power rating: 2.5 KW
Cutting disc diameter: Φ250 mm
Cutting spindle diameter: Φ20 mm
Cutting disc size: Φ250×Φ32×2 mm (optional Φ250×Φ25.4×2 mm)
Grinding disc diameter: Φ175 mm
Polishing pad speed (stepless via knob): 0–3000 r/min
Water inlet interface: outer diameter Φ21 mm
Drain pipe: inner diameter Φ32 mm
Workbench dimensions: 300×270 mm
Cutting worktable travel / motion: 200 mm / manual
Grinding worktable travel / motion: 10 mm / manual (accuracy 0.01 mm)
Grinding suction cup size: 60×90 mm
T-slot dimensions: see product images
Fixed suction cup: 60×45 mm (two 30×45 mm slides)
Optional horizontal transfer suction cup: 60×45 mm (stroke 10 mm, accuracy 0.01 mm)
Lighting: LED
Water tank capacity: 60 L (with integrated vacuum pump and vacuum separator)
External dimensions (W×D×H): 1233×770×548 mm
Net weight: 126 Kg

Technical characteristics / specifications

• Model designation: iqiege 10
• Supply: Single-phase AC 220V 50Hz
• Total power: 2.5 KW
• Cutting disc: Φ250 mm; spindle Φ20 mm; disc size Φ250×Φ32×2 mm (optional Φ250×Φ25.4×2 mm)
• Grinding disc: Φ175 mm
• Polishing pad speed: 0–3000 r/min (stepless via knob)
• Water inlet interface: outer diameter Φ21 mm
• Drain pipe: inner diameter Φ32 mm
• Workbench: 300×270 mm
• Cutting table travel: 200 mm (manual)
• Grinding table travel: 10 mm (manual), accuracy 0.01 mm
• Grinding suction cup: 60×90 mm
• Fixed suction cup: 60×45 mm (two 30×45 mm slides)
• Optional horizontal transfer suction cup: 60×45 mm (stroke 10 mm, accuracy 0.01 mm)
• Lighting: LED
• Water tank capacity: 60 L (with integrated vacuum pump and vacuum separator)
• External dimensions (W×D×H): 1233×770×548 mm
• Net weight: 126 Kg
• Design features: separate cutting and grinding chambers; coolant system to prevent sample overheating; manual table motions with high positioning accuracy
