TFT monitor R06L200-IPA1

resistive touch screenindustrialoutdoor

Overview
The Winmate R06L200-IPA1 is a 6.5-inch front IP65 industrial display designed for wet, dusty and outdoor-ready installations. The front bezel achieves IP65 protection when the unit is properly mounted in an enclosure. Ideal for factory automation, outdoor kiosks, pools/spa kiosks and other commercial or industrial environments requiring sealed front access.

Key features

• 6.5-inch TFT display, 640 x 480 resolution
• VGA input standard; HDMI and DVI optional
• Front IP65 waterproof and dustproof bezel
• Panel mount and VESA mount options
• Optional resistive touch screen or protection glass (no touch)

Certifications

• CE
• FCC

Product highlights

• Front IP65 protection: front bezel rated IP65 to prevent water and dust ingress when embedded in a sealed enclosure.
• Flexible touch options: available with resistive touch for operator input or with protection glass when touch is not required.
• Multiple video interfaces: VGA default with optional HDMI and DVI for easy integration with embedded boards and industrial systems.
• Easy sealing and installation: rear rubber O-ring on the front bezel provides a reliable seal against customer fixtures.
• Suitable for outdoor kiosks: when properly mounted, the front IP65 rating supports operation in humid or particle-prone environments.

Technical specifications

• Model: R06L200-IPA1
• Display - Size: 6.5 inches
• Display - Resolution: 640 x 480
• Display - Touch / Glass: Resistive Touch Screen (Optional); Protection Glass w/o Touch Function (Optional)
• Display - Panel Brightness: 700 nits
• Display - Contrast Ratio: 600:1
• Display - View Angles: 80, 80, 70, 70
• Display - Display Color: 16.2M Colors
• Display - Active Area: 132.48 x 99.36 mm
• Environment - Operating Humidity: 10% to 90% RH, Non-Condensing
• Environment - Operating Temperature: 0°C to 50°C
• Environment - Storage Temperature: -10°C to 60°C
• Certification: CE, FCC
• IO Ports - USB Port: 1 x USB for Touch Screen
• IO Ports - Video: 1 x VGA (Default); 1 x HDMI (Optional); 1 x DVI (Optional)
• Audio: Audio line in (3.5mm) (Optional); 2 x Speaker (Optional)
• Mechanical - Dimension: 218 x 164 x 50 mm
• Mechanical - Cut out: 191 x 142 mm
• Mechanical - Weight: 1.2 kg
• Mechanical - Mounting: VESA Mount / Panel Mount
• Mechanical - Enclosure: Metal Housing with Aluminum Bezel
• Mechanical - Cooling System: Fanless Design
• Accessory - Included: 1 x VGA cable; 1 x HDMI cable; 100~240V AC to DC Adapter; Power Cord; Manual; VESA screws (varies by product)
• Accessory - Optional: Remote Controller (Optional, varies by product)
• Power - Power Rating: 12V DC input (24V DC input optional)
• Control - Button: 5 Keys: -, +, Power, Esc, Enter
