Resistive touch screen monitor W24L100-CHA2TR

for displaysfor industrial machinesfor HMI interface

Overview
Winmate W24L100-CHA2TR is a 24-inch chassis transflective display for industrial visualization, control rooms and equipment monitoring. It integrates a 1920 x 1080 Full HD transflective panel, metal enclosure, fanless thermal design, VESA mounting and configurable touch and I/O options for integration into industrial systems.

Key Features

• 24-inch Full HD (1920 x 1080) transflective panel
• VGA (standard), HDMI and DVI options
• Chassis-mount form factor with VESA compatibility
• Resistive touch (default) with SAW or protection glass options
• Fanless design and metal enclosure for continuous industrial operation

Product details

• Improved readability in bright ambient light due to transflective technology
• Low power consumption and effective heat dissipation for 24/7 usage
• Flexible mounting: wall, desk, control cabinet or rack using VESA
• Multiple customization options for brightness, glass surface and I/O ports
• Control: 5 front keys (-, +, Power, Esc, Enter) and optional accessories (remote controller)

Certifications

• CE
• FCC

Technical specifications

• Model: W24L100-CHA2TR
• Touch / Glass: Resistive Touch Screen (Default); Protection Glass w/o Touch Function (Optional); SAW Touch (Optional)
• Size: 24.0 inches
• Resolution: 1920 x 1080 (Full HD)
• Panel Brightness: 350 nits
• Contrast Ratio: 3000:1
• View Angles: 89/89/89/89
• Display Color: 16.7M Colors
• Active Area: 527.04 x 296.46 mm
• Operating Humidity: 10% to 90% RH, non-condensing
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -10°C to 60°C
• IO Ports: 1 x USB for touch screen
• Video Inputs: 1 x VGA (Default); 1 x HDMI (Optional); 1 x DVI (Optional)
• Audio: Audio line in (3.5 mm) Optional; 2 x Speaker Optional
• Mechanical Dimension: 560 x 328 x 64 mm
• Mounting: VESA mount
• Enclosure: Metal
• Cooling System: Fanless design
• Power Rating: 12V DC input (24V DC optional)
• Accessories included: VGA cable; HDMI cable; 100~240V AC to DC Adapter; Power Cord; Manual; VESA screws (varies by product)
