Articulated robot PL80

5-axispalletizingpackaging

Overview
The MOTOMAN PL80 is a compact 5-axis palletising robot designed for high-speed palletising of boxes, cartons and packs in logistics and e-commerce applications. It handles payloads up to 80 kg and achieves high cycle rates, exceeding 800 cycles per hour.

Design & application
Low overall height, a slim profile and a small footprint allow installation in constrained spaces while providing sufficient horizontal and vertical reach for end-of-line palletising tasks. Internal cable routing increases system reliability for continuous operation.

Key features

• 5-axis palletising robot for high-speed handling
• Payload capacity up to 80 kg
• Compact, slim design with small footprint
• Suitable for box, carton and pack palletising in logistics and e-commerce
• Floor mounting option

Technical details
Number of axes: 5
Payload: 80 kg
Max. working range: 2061 mm
Repeatability: 0.03 mm
Weight: 565 kg
Power supply: 4.5 kVA
Maximum speed S axis: 180 °/s
Maximum speed L axis: 180 °/s
Maximum speed U axis: 180 °/s
Maximum speed B axis: 180 °/s
Maximum speed T axis: 500 °/s
Mounting options: floor

Technical specifications

• Model: PL80
• Series: PL Series
• Typical application: box/carton/pack palletising, e-commerce and logistics automation
• Performance: capable of achieving over 800 cycles per hour
