TFT LCD display module YX65202ACT

IPScapacitive touch screencolor

Product Name
Yousee YX65202ACT 6.52-inch 720×1600 IPS MIPI TFT LCD Display Module with Capacitive Touch

Description
The YX65202ACT is a 6.52-inch IPS TFT LCD module with 720×1600 HD+ resolution, integrated capacitive touch panel and MIPI DSI interface, designed for handheld devices, smart terminals, medical equipment and embedded systems. IPS technology and All-O'Clock wide viewing angle deliver consistent image quality and accurate color reproduction from all directions. The HD+ portrait format supports modern UI layouts and information-dense interfaces. The integrated capacitive touch supports smooth, responsive multi-touch interaction. The slim module profile facilitates integration into compact and portable device designs.

Basic Specifications
Display Size: 6.52 inch
LCD Type: IPS TFT-LCD, Transmissive
Resolution: 720 (RGB) × 1600
Touch Panel: Capacitive Touch (CTP)
Active Area: 68.04 × 150.96 mm
Outline Dimensions: 72.00 × 161.10 × 3.20 mm
Pixel Pitch: 0.0945 × 0.0945 mm
Viewing Direction: All-O'Clock
Driver IC: ILI9881C
Interface: MIPI DSI

Optical Characteristics
Resolution: 720 × 1600
Contrast Ratio: 800 : 1
Color Gamut: 60%
Luminance: 400 cd/m²
Luminance Uniformity: 80%
Viewing Angle (CR ≥ 10): 80° (All directions)
Response Time: 25 ms

Operating Conditions
Operating Temperature: -20°C ~ +70°C
Storage Temperature: -30°C ~ +80°C
Humidity: ≤ 90% RH (60°C)

Mechanical Drawing
Mechanical drawing is provided for outline and mounting dimensions.

Technical specifications

• Display Size: 6.52 inch
• LCD Type: IPS TFT-LCD, Transmissive
• Resolution: 720 (RGB) × 1600
• Touch Panel: Capacitive Touch (CTP)
• Active Area: 68.04 × 150.96 mm
• Outline Dimensions: 72.00 × 161.10 × 3.20 mm
• Pixel Pitch: 0.0945 × 0.0945 mm
• Viewing Direction: All-O'Clock
• Driver IC: ILI9881C
• Interface: MIPI DSI
• Contrast Ratio: 800 : 1
• Color Gamut: 60%
• Luminance: 400 cd/m²
• Luminance Uniformity: 80%
• Viewing Angle (CR ≥ 10): 80° (All directions)
• Response Time: 25 ms
• Operating Temperature: -20°C ~ +70°C
• Storage Temperature: -30°C ~ +80°C
• Humidity: ≤ 90% RH (60°C)
