Chain sling Grade 80 SOG

1-pointsteel

Product Name
Grade 80 SOG Chain Sling - Single Leg w/ Oblong Master Link on Top and Grab Hook on Bottom

Brief

• Sling style: Chain sling
• Individualized serial number
• Chain size & grade
• Exact length supplied per order
• Working Load Limit (WLL)

Introduction
The chain sling is supplied with written certification.
The serial number on the tag corresponds to the certificate and your sales order number to ensure complete traceability.

Parameter
Chain Diameter | 1-Leg (90°) | 1-Leg (60°) | 1-Leg (45°) | 1-Leg (30°) | 2-Leg (60°) | 2-Leg (45°) | 2-Leg (30°)
Load Factor | 1 | 1.7 | 1.4 | 1 | 2.6 | 2.1 | 1.45
7/32″ | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
9/32″ | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
5/16″ | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
3/8″ | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
1/2″ | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
5/8″ | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
3/4″ | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
7/8″ | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
1″ | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
1-1/4″ | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

Standards

• Name: Grade 80 SOG Chain Sling – Single Leg w/ Oblong Master Link on Top and Grab Hook on Bottom
• MOQ: 100 Meters
• Package: Carton + Steel Pallet

Features / Technical specifications

• Product name: Grade 80 SOG Chain Sling
• Sling configuration: Single leg (oblong master link on top and grab hook on bottom)
• Sling style: Chain sling
• Serial number: Individualized serial number on tag for traceability; serial coordinates with certification and sales order
• Certification: Written certification provided; full traceability between tag serial and certificate
• Chain size & grade: Multiple chain diameters available (7/32″ to 1-1/4″) with corresponding WLL by angle
• Design factor: 4:1
• Load factors by configuration/angle: 1-Leg (90°=1, 60°=1.7, 45°=1.4, 30°=1), 2-Leg (60°=2.6, 45°=2.1, 30°=1.45)
• Working load limits: See parameter table for values (example: 1/2″ 1-Leg 90° = 12,000 lb; 2-Leg 60° = 31,200 lb)
• Exact length: Supplied to exact length per customer order
• MOQ: 100 Meters
• Packaging: Carton plus steel pallet
