Chain sling Grade 100 SGG

1-pointsteel

Overview

• Grade 100 SGG Chain Sling – Single Leg Chain Sling with Grab Hook at Both Ends
• Key attributes: Sling Style; Individualized Serial Number; Chain Size & Grade; Exact Length of the Sling; Working Load Limit

Introduction

• S = Sling Leg
• T = Triple Leg
• S = Sling Hook (w/latch)
• SL = Self Locking (Safety) Hook
• F = Foundry Hook
• D = Double Leg
• Q = Quad Leg
• G = Grab Hook
• O = Oblong Master Link

Certification / Traceability

• The chain sling is provided with a written certification. The serial number on the tag will coordinate with the certificate and your sales order number to ensure complete traceability.

Parameter (Design factors and Working Load Limits)
Chain Size | 1-Leg (Load Factor: 1) | 2-Leg (Load Factor: 1.7) | 2-Leg (Load Factor: 1.4) | 2-Leg (Load Factor: 1) | 3/4-Leg (Load Factor: 2.6) | 3/4-Leg (Load Factor: 2.1) | 3/4-Leg (Load Factor: 1.45)
7/32" | 2,700 | 4,700 | 3,800 | 2,700 | 7,000 | 5,700 | 4,000
9/32" | 4,300 | 7,400 | 6,100 | 4,300 | 11,200 | 9,100 | 6,400
5/16" | 5,700 | 9,900 | 8,100 | 5,700 | 14,800 | 12,100 | 8,500
3/8" | 8,800 | 15,200 | 12,400 | 8,800 | 22,900 | 18,700 | 13,200
1/2" | 15,000 | 26,000 | 21,200 | 15,000 | 39,000 | 31,800 | 22,500
5/8" | 22,600 | 39,100 | 32,000 | 22,600 | 58,700 | 47,900 | 33,900
3/4" | 35,300 | 61,100 | 49,900 | 35,300 | 91,700 | 74,900 | 53,000
7/8" | 42,700 | 74,000 | 60,400 | 42,700 | 110,900 | 90,600 | 64,000
1" | 59,700 | 103,400 | 84,400 | 59,700 | 155,100 | 126,600 | 89,550
1-1/4" | 90,400 | 156,600 | 127,800 | 90,400 | 234,900 | 191,800 | 135,600

Standards & Commercial Info

• Name: Grade 100 SGG Chain Sling – Single Leg Chain Sling w/ Grab Hook Both Ends
• MOQ: 100 Meters
• Package: Carton + Steel Pallet

Characteristics / Technical specifications

• Product name: Grade 100 SGG Chain Sling
• Model/Type: SGG Chain Sling (single leg configuration shown)
• Grade: Grade 100
• Sling styles available: single leg, double leg, triple leg, quad leg
• Hook types available: Sling Hook (w/latch), Self Locking (Safety) Hook, Foundry Hook, Grab Hook
• Identification: Individualized serial number on tag; written certification supplied; serial matches certificate for traceability
• Design factor: 4:1
• Load factors by configuration: 1-Leg = 1; 2-Leg variants = 1.7 / 1.4 / 1 (depending on angle/configuration); 3-/4-Leg variants = 2.6 / 2.1 / 1.45 (depending on angle/configuration)
• Chain sizes and corresponding working load limits: see parameter table above for detailed values per chain size and sling configuration
• Minimum order quantity: 100 meters
• Packing: Carton plus steel pallet for shipment
