Chain sling Grade 80 SSLG Chain Sling

1-pointsteelfor safety

Product Overview
Grade 80 SSLG Chain Sling — Single Leg with Self-Locking (Safety) Hook on Top and Grab Hook on Bottom. Configurable options include sling style, chain diameter and grade, exact sling length and rated working load limits (WLL). Individual serial number and certificate provided for each sling.

Introduction

• S = Sling Leg
• T = Triple Leg
• S (alt) = Sling Hook (w/latch)
• SL = Self Locking (Safety) Hook
• F = Foundry Hook
• D = Double Leg
• Q = Quad Leg
• G = Grab Hook
• O = Oblong Master Link

Certification & Traceability
The chain sling is supplied with written certification. The serial number on the tag matches the certificate and the sales order for full traceability and quality control documentation.

Parameter
Design factor: 4:1 (general). Load factor reference per sling configuration: 1-Leg Sling (90° / 60° / 45° / 30°) and 2-Leg Sling (60° / 45° / 30°).

Chain Diameter — 1-Leg: 90° / 60° / 45° / 30° — 2-Leg: 60° / 45° / 30°
7/32" — 2,100 / 3,600 / 3,000 / 2,100 — 5,500 / 4,400 / 3,200
9/32" — 3,500 / 6,100 / 4,900 / 3,500 — 9,100 / 7,400 / 5,200
5/16" — 4,500 / 7,800 / 6,400 / 4,500 — 11,700 / 9,500 / 6,800
3/8" — 7,100 / 12,300 / 10,000 / 7,100 — 18,400 / 15,100 / 10,600
1/2" — 12,000 / 20,800 / 17,000 / 12,000 — 31,200 / 25,500 / 18,000
5/8" — 18,100 / 31,300 / 25,600 / 18,100 — 47,000 / 38,400 / 27,100
3/4" — 28,300 / 49,000 / 40,000 / 28,300 — 73,500 / 60,000 / 42,400
7/8" — 34,200 / 59,200 / 48,400 / 34,200 — 88,900 / 72,500 / 51,300
1" — 47,700 / 82,600 / 67,400 / 47,700 — 123,900 / 101,200 / 71,500
1-1/4" — 72,300 / 125,200 / 102,200 / 72,300 — 187,800 / 153,400 / 108,500

Standards
Name: Grade 80 SSLG Chain Sling — Single Leg with Self Locking (Safety) Hook on Top and Grab Hook on Bottom
MOQ: 100 Meters
Package: Carton + Steel Pallet

Technical features / specifications

• Commercial name: Grade 80 SSLG Chain Sling
• Sling styles available: single leg, double leg, triple leg, quad leg (configurable)
• Hook types: Self Locking (Safety) Hook, Grab Hook, Sling Hook (w/latch), Foundry Hook
• Individual serial number for each sling; certificate provided for traceability
• Chain sizes available: from 7/32" up to 1-1/4" (see parameter table for working load limits per configuration and angle)
• Design factor: 4:1
• MOQ: 100 meters
• Packaging: Carton plus steel pallet
