Chain sling Grade 80 DOF

2-pointsteel

Product Overview
Grade 80 DOF chain sling in a double-leg configuration with an oblong master link on top and foundry hooks on the bottom. Supplied with individualized serial tag; available in multiple chain sizes and custom lengths for industrial lifting applications requiring certified traceability.

Introduction

• S = Sling Leg
• T = Triple Leg
• S (hook) = Sling Hook (with latch)
• SL = Self Locking (Safety) Hook
• F = Foundry Hook
• D = Double Leg
• Q = Quad Leg
• G = Grab Hook
• O = Oblong Master Link

Certification & Traceability
The chain sling is delivered with written certification. The serial number on the tag corresponds to the certificate and your sales order number to ensure full traceability for inspection and maintenance records.

Working Load Limits (WLL) & Parameters

• Design factor: 4:1
• Load factors by sling type and angle: 1 (90° for 1-leg), 1.7 (60° for 1-leg), 1.4 (45° for 1-leg), 1 (30° for 1-leg); 2.6 (60° for 3-/4-leg), 2.1 (45° for 3-/4-leg), 1.45 (30° for 3-/4-leg)
• Chain diameters and example Working Load Limits (by configuration and angle):
  • 7/32" — 2,100; 3,600; 3,000; 2,100; 5,500; 4,400; 3,200
  • 9/32" — 3,500; 6,100; 4,900; 3,500; 9,100; 7,400; 5,200
  • 5/16" — 4,500; 7,800; 6,400; 4,500; 11,700; 9,500; 6,800
  • 3/8" — 7,100; 12,300; 10,000; 7,100; 18,400; 15,100; 10,600
  • 1/2" — 12,000; 20,800; 17,000; 12,000; 31,200; 25,500; 18,000
  • 5/8" — 18,100; 31,300; 25,600; 18,100; 47,000; 38,400; 27,100
  • 3/4" — 28,300; 49,000; 40,000; 28,300; 73,500; 60,000; 42,400
  • 7/8" — 34,200; 59,200; 48,400; 34,200; 88,900; 72,500; 51,300
  • 1" — 47,700; 82,600; 67,400; 47,700; 123,900; 101,200; 71,500
  • 1-1/4" — 72,300; 125,200; 102,200; 72,300; 187,800; 153,400; 108,500

Standards & Logistics
Name: Grade 80 DOF Chain Sling — Double Leg with Oblong Master Link on Top and Foundry Hooks on Bottom
MOQ: 100 Meters
Packaging: Carton + Steel Pallet for shipment

Technical specifications

• Name: Grade 80 DOF Chain Sling — Double Leg with Oblong Master Link on Top and Foundry Hooks on Bottom
• Sling style: Double Leg (D) — other configurations available per code key (S, T, SL, F, Q, G, O)
• Design factor: 4:1
• Serial number on tag coordinates with certificate for full traceability
• Minimum Order Quantity (MOQ): 100 meters
• Packaging: Carton plus steel pallet
