Chain sling Grade 80 DOSL

2-pointsteelfor safety

Product Overview

• Sling style: DOSL — double-leg with oblong master link on top and self-locking hooks on bottom
• Certification & traceability: written certificate supplied; serial number on tag matches certificate and sales order
• Chain grade: Grade 80
• Chain diameter options: 7/32" to 1-1/4"
• Length: customizable per order
• Working Load Limit (WLL): see Parameter table below by chain diameter and leg configuration

Introduction

• S = Sling leg
• T = Triple leg
• SH = Sling hook (with latch)
• SL = Self-locking (safety) hook
• F = Foundry hook
• D = Double leg
• Q = Quad leg
• G = Grab hook
• O = Oblong master link

Additional Notes

• Each chain sling is supplied with written certification.
• The serial number on the tag coordinates with the certificate and the sales order number to ensure full traceability.

Parameter
Design factor: 4:1
Load factors by angle and configuration are indicated below.

Chain Diameter | 1-Leg (90°) | 2-Leg (60°) | 2-Leg (45°) | 2-Leg (30°) | 3/4-Leg & 4-Leg (60°) | 3/4-Leg & 4-Leg (45°) | 3/4-Leg & 4-Leg (30°)
7/32" | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
9/32" | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
5/16" | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
3/8" | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
1/2" | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
5/8" | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
3/4" | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
7/8" | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
1" | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
1-1/4" | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

Standards

• Name: Grade 80 DOSL Chain Sling — Double-leg oblong master link on top and self-locking hooks on bottom
• Minimum order quantity (MOQ): 100 meters
• Packing: carton plus steel pallet

Technical Specifications

• Product name: Grade 80 DOSL Chain Sling (double-leg with oblong master link on top and self-locking hooks on bottom)
• Grade: 80
• Sling configurations: supports 1-leg, 2-leg (DOSL), 3-leg and 4-leg as per parameters
• Design factor: 4:1
• Working Load Limits and load factors: detailed in the Parameter section above
• Chain diameter options and corresponding WLLs: see Parameter table (7/32" up to 1-1/4")
• Certification & traceability: written certification provided; serial number on tag coordinates with certificate and sales order
• MOQ: 100 meters
• Packing: carton + steel pallet
• Length: customized per order
