1-point sling Grade 80 SGG Chain Sling

chainhigh strength steel

Overview
Grade 80 SGG chain sling — single-leg configuration with grab hooks on both ends. Supplied with individualized serial tag and written certification; working load limits vary by chain diameter and sling configuration.

Introduction
The sling is issued with a written certificate. The serial number on the tag corresponds to the certificate and the sales order for full traceability and inspection records.

Parameter
Design factor referenced: 4:1

• Chain Diameter | 90° (Load Factor: 1) | 60° (Load Factor: 1.7) | 45° (Load Factor: 1.4) | 30° (Load Factor: 1) | 60° (Load Factor: 2.6) | 45° (Load Factor: 2.1) | 30° (Load Factor: 1.45)
• 7/32″ | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
• 9/32″ | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
• 5/16″ | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
• 3/8″ | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
• 1/2″ | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
• 5/8″ | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
• 3/4″ | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
• 7/8″ | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
• 1″ | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
• 1-1/4″ | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

Standards

• Name: Grade 80 SGG Chain Sling – Single Leg with Grab Hook on Both Ends
• MOQ: 100 Meters
• Package: Carton + Steel Pallet

Technical specifications

• Product: Grade 80 SGG chain sling — single-leg (other leg counts configurable)
• Sling style: Single leg (available in 1-, 2-, 3- and 4-leg configurations)
• Individualized serial number on tag; tag matches written certification for traceability
• Chain size & grade: Grade 80 — multiple diameters listed in parameters
• Exact sling length: configured to customer specification
• Working Load Limit (WLL): values vary by chain diameter and configuration — see parameter table above
• Design factor: 4:1 referenced
• Load factors by angle provided for each configuration (examples: 90°, 60°, 45°, 30°)
• Supply: Supplied with written certification
• Minimum order quantity: 100 meters
• Packing: Carton plus steel pallet
