Chain sling Grade 80 SSLSL

1-pointsteelfor safety

Overview

• Sling style: Single-leg chain sling
• Individualized serial number
• Chain size & grade
• Exact sling length
• Working load limit

Introduction
The chain sling is supplied with written certification. The serial number on the tag corresponds to the certificate and your sales order number to ensure full traceability throughout the supply chain.

Parameter
Design Factor | 1-Leg Sling | 2-Leg Sling | 3-Leg & 4-Leg Slings
4:1 | (illustration for 1-leg shown) | (illustration for 2-leg shown spanning 3 columns) | (illustration for 3/4-leg shown spanning 3 columns)

Chain Diameter / Angle Load Factors and Working Loads (values shown as per table)
Headers: Chain Diameter | 90 Degrees (Load Factor: 1) | 60 Degrees (Load Factor: 1.7) | 45 Degrees (Load Factor: 1.4) | 30 Degrees (Load Factor: 1) | 60 Degrees (Load Factor: 2.6) | 45 Degrees (Load Factor: 2.1) | 30 Degrees (Load Factor: 1.45)
7/32" | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
9/32" | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
5/16" | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
3/8" | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
1/2" | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
5/8" | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
3/4" | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
7/8" | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
1" | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
1-1/4" | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

Standards
Name: Grade 80 SSLSL Chain Sling – Single Leg w/ Self Locking (Safety) Hooks Both Ends
MOQ: 100 Meters
Package: Carton + Steel Pallet

Features / Technical Specifications

• Product type: Grade 80 SSLSL Chain Sling (single leg)
• Design factor: 4:1
• Material grade: Grade 80
• Self-locking (safety) hooks fitted at both ends (single-leg configuration)
• Traceability: Supplied with written certification; serial number on tag matches certification for full traceability
• Available chain diameters (examples): 7/32", 9/32", 5/16", 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1-1/4" with corresponding working loads as per parameter table
• Minimum order quantity (MOQ): 100 Meters
• Packaging: Carton + Steel Pallet
