Chain sling Grade 80 SOSL

1-pointsteel

Product Overview
Grade 80 SOSL chain sling — single leg with oblong master link on top and clevis self locking (safety) hook on bottom. Includes sling style identification, individualized serial number, chain size & grade, exact sling length and working load limit.

Introduction

• S = Sling Leg
• T = Triple Leg
• S = Sling Hook (w/latch)
• SL = Self Locking (Safety) Hook
• F = Foundry Hook
• D = Double Leg
• Q = Quad Leg
• G = Grab Hook
• O = Oblong Master Link

The chain sling is provided with a written certification. The serial number on the tag will coordinate with the certificate and the sales order number to ensure complete traceability.

Parameters (table)
Design Factor | 1-Leg Sling | 2-Leg Sling | 3-Leg & 4-Leg Slings
Chain Diameter | 90 Degrees | 60 Degrees | 45 Degrees | 30 Degrees | 60 Degrees | 45 Degrees | 30 Degrees
Load Factor: | 1 | 1.7 | 1.4 | 1 | 2.6 | 2.1 | 1.45
7/32" | 2,100 | 3,600 | 3,000 | 2,100 | 5,500 | 4,400 | 3,200
9/32" | 3,500 | 6,100 | 4,900 | 3,500 | 9,100 | 7,400 | 5,200
5/16" | 4,500 | 7,800 | 6,400 | 4,500 | 11,700 | 9,500 | 6,800
3/8" | 7,100 | 12,300 | 10,000 | 7,100 | 18,400 | 15,100 | 10,600
1/2" | 12,000 | 20,800 | 17,000 | 12,000 | 31,200 | 25,500 | 18,000
5/8" | 18,100 | 31,300 | 25,600 | 18,100 | 47,000 | 38,400 | 27,100
3/4" | 28,300 | 49,000 | 40,000 | 28,300 | 73,500 | 60,000 | 42,400
7/8" | 34,200 | 59,200 | 48,400 | 34,200 | 88,900 | 72,500 | 51,300
1" | 47,700 | 82,600 | 67,400 | 47,700 | 123,900 | 101,200 | 71,500
1-1/4" | 72,300 | 125,200 | 102,200 | 72,300 | 187,800 | 153,400 | 108,500

Standards
Name: Grade 80 SOSL Chain Sling – Single Leg w/ Oblong Master Link on Top and Clevis Self Locking Hook on Bottom
MOQ: 100 meters
Package: Carton + Steel Pallet

Technical specifications

• Brand: TOPONE CHAIN
• Commercial name: Grade 80 SOSL Chain Sling
• Grade: Grade 80
• Sling configuration: Single Leg (options available for Double, Triple, Quad)
• Top fitting: Oblong Master Link
• Bottom fitting: Clevis Self Locking (Safety) Hook (SL)
• Serial number: Individualized serial number on tag; written certification provided for traceability
• Design factor: 4:1
• Chain diameters available: 7/32", 9/32", 5/16", 3/8", 1/2", 5/8", 3/4", 7/8", 1", 1-1/4"
• Working load limits: provided per chain diameter and sling angle (see Parameters block)
• MOQ: 100 meters
• Packaging: Carton plus steel pallet
