LED floodlight JNFLM20-600S-5000-A8-DIM

HIDIP65bracket-mounted

Description
Modular 600 W LED flood light in a 2×4 module configuration delivering 78,000 lm at 6000 K. Fitted with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Dimmable with a wide square beam (140×140°) and IP65 protection for outdoor industrial applications. Die-cast aluminum housing with adjustable bracket mount. Designed to replace 1000 W metal halide/HID/HPS installations while reducing maintenance and energy consumption.

Features

• Configuration: 2×4 LED modules
• LED: Philips Lumileds (Luxeon TX)
• Driver: Meanwell driver(s)
• Dimmable
• Ingress Protection: IP65
• Beam pattern: 140×140° (square)
• Colour temperature: 6000 K (cool white)
• High lumen output replacing 1000 W metal halide/HID/HPS

Specification Details (table)
Product SKU: JNFLM20-600S-5000-A8-DIM
Power Consumption: 600 W
System Power: 606 W
Input Voltage: 100-277V
Input Frequency: 50/60 Hz
Beam Angle (°): 140x140°
IP Rating: IP65
Color Rendering Index: >80
LED Type: Philips Lumileds (Luxeon TX)
Total Lumens Output: 78,000 lm
Color Temperature (K): 6000 K
IK Impact Rating: IK08
Dimming Capability: Dimmable
Housing Colour: Black
Power Factor: >0.95
Housing Material: Die-cast Aluminum
Warranty Period (Years): 5
Input Voltage Range: 100-277V
Power Factor: >0.95
Number of LED Modules: 8
Environmental Temperature Range: -20°C ~ 45°C
Mounting Type: Adjustable Bracket Mount
Fixture Height (mm): 113 mm
Fixture Length (mm): 326 mm
Fixture Width (mm): 128 mm
Product Weight: 17.2 kg
LED Driver Brand: Meanwell driver(s)
Working Temperature Range: -20°C ~ 45°C
Working Humidity Range: 10%-90% RH
Lifespan (Hours): 50,000 hours

Technical specifications

• SKU: JNFLM20-600S-5000-A8-DIM
• Power Consumption: 600 W
• System Power: 606 W
• Input Voltage: 100-277V
• Input Frequency: 50/60 Hz
• LED Type: Philips Lumileds (Luxeon TX)
• LED Driver: Meanwell driver(s)
• Total Lumens: 78,000 lm
• Colour Temperature: 6000 K (cool white)
• CRI: >80
• Beam Angle: 140×140° (square)
• IK Rating: IK08
• IP Rating: IP65
• Power Factor: >0.95
• Housing Material: Die-cast Aluminum
• Housing Colour: Black
• Mounting: Adjustable Bracket Mount
• Fixture Dimensions (L×W×H): 326×128×113 mm
• Product Weight: 17.2 kg
• Operating Temperature: -20°C to 45°C
• Operating Humidity: 10%–90% RH
• Lifespan: 50,000 hours
• Warranty: 5 years
