LED floodlight JNFLM14-200S-6500-A1-DIM

HIDHPSIP65

Product Short Description
200W modular LED flood light in a 1×3 module configuration, fitted with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Dimmable and rated IP65 for outdoor use. Replaces 400W metal halide / HID / HPS luminaires.

Features

• Modular 1×3 LED module configuration
• Original Philips Lumileds (Luxeon TX) LEDs
• Meanwell driver(s)
• Dimmable
• IP65 ingress protection
• Replaces 400W metal halide / HID / HPS

Product Specifications
Product SKU: JNFLM14-200S-6500-A1-DIM
Power Consumption: 200 W
Input Voltage: 100-277 V
Beam Angle: 15×15°
IP Rating: IP65
Color Rendering Index (CRI): >80
LED Type: Philips Lumileds (Luxeon TX)
Total Lumens Output: 26000 lm
Color Temperature: 6000 K
IK Impact Rating: IK08
Dimming Capability: Dimmable
Housing Colour: Black
Power Factor: >0.95
Input Frequency: 50/60 Hz
Housing Material: Die-cast Aluminum
Warranty Period: 5 years
System Power: 206 W
Number of LED Modules: 1 module
Environmental Temperature Range: -20°C ~ 45°C
Mounting Type: Adjustable Bracket Mount
Fixture Dimensions (L×W×H): 326 × 128 × 113 mm
Product Weight: 8.2 kg
LED Driver Brand: Meanwell
Lifespan: 50,000 hours

Packaging & Shipping
Product Dimensions (mm): 326 × 128 × 113 mm
Net Weight: 8.2 kg
Export Carton Dimensions (mm): 400 × 360 × 230 mm
Products per Carton: 1
Export Carton Gross Weight: 8 kg

Specification Details
200W modular LED flood light, configuration 1×3 modules, with original Philips Lumileds (Luxeon TX) and Meanwell driver(s). Dimmable. IP65. Replaces 400W metal halide/HID/HPS.

Technical Specifications

• Power Consumption: 200 W
• Input Voltage: 100-277 V
• Beam Angle: 15×15°
• IP Rating: IP65
• CRI: >80
• LED Type: Philips Lumileds (Luxeon TX)
• Total Lumens: 26000 lm
• Colour Temperature: 6000 K
• IK Rating: IK08
• Dimming: Dimmable
• Power Factor: >0.95
• Input Frequency: 50/60 Hz
• Housing Material: Die-cast Aluminum
• Warranty: 5 years
• System Power: 206 W
• Number of LED Modules: 1
• Operating Temperature Range: -20°C ~ 45°C
• Working Humidity Range: 10%-90% RH
• Lifespan: 50,000 hours
• Mounting Type: Adjustable Bracket Mount
• Fixture Dimensions (L×W×H): 326 × 128 × 113 mm
• Product Weight: 8.2 kg
