LED floodlight JNFLM14-200S-6500-A2-ND

HIDHPSIP65

Product summary
200W modular LED flood light with 1x3 module configuration (3 LED modules), fitted with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Non-dimmable. IP65-rated housing for outdoor industrial applications. Suitable as a retrofit to 400W metal halide/HID/HPS installations.

Features

• Modular design (1x3 modules)
• Philips Lumileds (Luxeon TX) LEDs
• Meanwell driver(s)
• High luminous flux (approx. 26,000 lm)
• IP65 and IK08 protection for outdoor use

Specification Details (as listed on page)
Product SKU: JNFLM14-200S-6500-A2-ND
Power Consumption: 200 W
System Power: 206 W
Input Voltage: 100-277V
Input Frequency: 50/60 Hz
Beam Angle: 30x30°
LED Type: Philips Lumileds (Luxeon TX)
Total Lumens Output: 26,000 lm
Colour Temperature: 6000 K (cool white)
CRI: >80
Dimming Capability: Non-dimmable
IP Rating: IP65
IK Rating: IK08
Power Factor: >0.95
Housing Material: Die-cast aluminum, black
Mounting Type: Adjustable bracket mount
Dimensions (LxWxH): 326 x 128 x 113 mm
Fixture Weight: 8.2 kg
Operating Temperature: -20°C to 45°C
Operating Humidity: 10%-90% RH
Lifespan: 50,000 hours
Warranty: 5 years

Packaging & Shipping (as listed)
Product Dimensions (mm): 326 x 128 x 113 mm
Net Weight: 8.2 kg
Export Carton Dimensions (mm): 400 x 360 x 230 mm
Products per Carton: 1
Export Carton Gross Weight: 8 kg

Technical specifications

• Power consumption: 200 W (system 206 W)
• Luminous flux: 26,000 lm
• LED: Philips Lumileds (Luxeon TX)
• Driver: Meanwell driver(s)
• Colour temperature: 6000 K (cool white)
• CRI: >80
• Beam angle: 30x30°
• IP/IK rating: IP65 / IK08
• Input voltage: 100-277V, 50/60 Hz
• Housing: Die-cast aluminum, black
• Mounting: Adjustable bracket
• Dimensions: 326 x 128 x 113 mm
• Weight: 8.2 kg
• Operating temp.: -20°C to 45°C
• Humidity: 10%-90% RH
• Lifespan: 50,000 hours
• Warranty: 5 years
