LED floodlight JNFLM14-200S-6500-A8-ND

HIDHPSIP65

Short description
200W modular LED flood light, configuration 1x3 LED modules with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Non-dimmable. IP65 rated for outdoor use. Replaces conventional 400W metal halide / HID / HPS fixtures while delivering approximately 26,000 lm.

Features

• Configuration: 1x3 LED modules
• LED: Philips Lumileds (Luxeon TX)
• Driver: Meanwell driver(s)
• Non-dimmable
• Ingress protection: IP65 (suitable for outdoor installations)
• Beam angle: 140×140° (square beam)
• High lumen output to replace 400W metal halide/HID/HPS equivalents

Product Specifications
Product SKU: JNFLM14-200S-6500-A8-ND
Power Consumption: 200 W
System Power: 206 W
Input Voltage: 100-277 V
Input Frequency: 50/60 Hz
Beam Angle (°): 140×140°
Total Lumens Output: 26,000 lm
Color Temperature (K): 6000 K (cool white)
Color Rendering Index (CRI): >80
LED Type: Philips Lumileds (Luxeon TX)
LED Driver Brand: Meanwell driver(s)
Dimming Capability: Non-dimmable
Power Factor: >0.95
IK Impact Rating: IK08
IP Rating: IP65
Housing Material: Die-cast aluminum
Housing Colour: Black
Number of LED Modules: 3
Fixture Height (mm): 113 mm
Fixture Length (mm): 326 mm
Fixture Width (mm): 128 mm
Product Weight: 8.2 kg
Environmental Temperature Range: -20°C ~ 45°C
Working Humidity Range: 10%–90% RH
Lifespan (Hours): 50,000 hours
Warranty Period (Years): 5

Packaging & Shipping
Product Dimensions (mm): 326×128×113 mm
Net Weight (kg): 8.2 kg
Export Carton Dimensions (mm): 400×360×230 mm
Products per Carton: 1
Export Carton Gross Weight (kg): 8 kg

Technical specifications

• Rated Power: 200 W
• System Power: 206 W
• Lumens: 26,000 lm
• Correlated Colour Temperature (CCT): 6000 K (cool white)
• CRI: >80
• Beam Angle: 140×140° (square)
• IP Rating: IP65
• IK Rating: IK08
• Input Voltage: 100–277 V, 50/60 Hz
• Power Factor: >0.95
• Housing: Die-cast aluminum, black
• Mounting: Adjustable bracket
• Operating Temperature: -20°C to 45°C
• Relative Humidity: 10%–90% RH
• Lifespan: 50,000 hours
• Warranty: 5 years
