LED floodlight JNFLM14-200S-5000-A8-DIM

HIDHPSIP65

Product Overview
200W modular LED flood light, 1x3 module configuration, cool white 6000 K, with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Dimmable, wide square beam 140×140°, IP65 and IK08 rated. Designed to replace 400W metal halide/HID/HPS luminaires in industrial and exterior applications.

Features

• High output 200 W modular floodlight
• Philips Lumileds (Luxeon TX) LED package
• Meanwell driver(s)
• Dimmable
• Wide square beam angle 140×140°
• IP65 ingress protection and IK08 impact rating
• Die-cast aluminium housing in black
• High power factor >0.95
• Designed to replace 400 W metal halide/HID/HPS

Packaging & Shipping
Product Dimensions (mm): 326x128x113mm
Net Weight (kg): 8.2 kg
Export Carton Dimensions (mm): 400x360x230
Products per Carton: 1
Export Carton Gross Weight (kg): 8 kg
Fixture Height (mm): 113
Fixture Width (mm): 128
Fixture Length (mm): 326

Technical specifications

• Product SKU: JNFLM14-200S-5000-A8-DIM
• Power Consumption: 200 W
• Input Voltage: 100-277V
• Beam Angle (°): 140x140°
• IP Rating: IP65
• Color Rendering Index (CRI): >80
• LED Type: Philips Lumileds (Luxeon TX)
• Total Lumens Output: 26000 lm
• Colour Temperature: 6000 K
• IK Impact Rating: IK08
• Dimming Capability: Dimmable
• Housing Colour: Black
• Power Factor: >0.95
• Input Frequency: 50/60 Hz
• Housing Material: Die-cast Aluminum
• Warranty Period: 5 years
• System Power: 206 W
• Number of LED Modules: 1 module
• Beam Angle Square: 140x140°
• Environmental Temperature Range: -20°C ~ 45°C
• Mounting Type: Adjustable Bracket Mount
• Fixture Height: 113 mm
• Fixture Length: 326 mm
• Fixture Width: 128 mm
• Product Weight: 8.2 kg
• LED Driver Brand: Meanwell driver(s)
• Working Temperature Range: -20°C ~ 45°C
• Working Humidity Range: 10%-90% RH
• Lifespan: 50,000 hours
