LED floodlight JNFLM14-200S-6500-A7-DIM

HIDHPSIP65

Product short description
200W modular LED flood light configured as 1×3 modules, fitted with original Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Dimmable, beam angle 50×140°, IP65 rated. Replaces 400W metal halide/HID/HPS units. Adjustable bracket mounting for outdoor industrial applications.

Features

• Modular 1×3 LED modules
• Original Philips Lumileds (Luxeon TX) LEDs
• Meanwell driver(s)
• Dimmable (supports external dimming control)
• IP65 ingress protection
• IK08 impact rating
• Adjustable bracket mount

Product specifications

• Product SKU: JNFLM14-200S-6500-A7-DIM
• Power Consumption: 200 W
• System Power: 206 W
• Input Voltage: 100-277 V
• Input Frequency: 50/60 Hz
• Beam Angle: 50×140°
• Total Luminous Flux: 26,000 lm
• Color Temperature: 6,000 K (cool white)
• Color Rendering Index (CRI): >80
• LED Type: Philips Lumileds (Luxeon TX)
• LED Driver Brand: Meanwell driver(s)
• Dimming Capability: Dimmable
• IP Rating: IP65
• IK Rating: IK08
• Power Factor: >0.95
• Housing Material: Die-cast aluminum
• Housing Colour: Black
• Mounting Type: Adjustable bracket mount
• Fixture Dimensions (L×W×H): 326 × 128 × 113 mm
• Product Weight: 8.2 kg
• Operating Temperature Range: -20°C to 45°C
• Working Humidity Range: 10% - 90% RH
• Lifespan: 50,000 hours
• Warranty: 5 years
