LED floodlight JNFLM14-200S-6500-A1-ND

IP65IK 08outdoor

Description
200W modular LED flood light (configuration 1x3 modules) JNFLM14-200S-6500-A1-ND fitted with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Non-dimmable. 15x15° square beam, 6000 K cool white, IP65 and IK08 rated — designed for industrial outdoor lighting of yards, facades, low-angle accent and area illumination.

Product Specifications

• SKU: JNFLM14-200S-6500-A1-ND
• Power Consumption: 200 W (System Power: 206 W)
• Input Voltage: 100-277 V
• Input Frequency: 50/60 Hz
• LED Type: Philips Lumileds (Luxeon TX)
• LED Driver: Meanwell driver(s)
• Total Lumen Output: 26,000 lm
• Colour Temperature: 6,000 K (cool white)
• CRI: >80
• Beam Angle: 15x15° (square)
• IP Rating: IP65
• IK Rating: IK08
• Power Factor: >0.95
• Number of LED Modules: 1x3 modules
• Housing Material: Die-cast aluminum
• Housing Colour: Black

Packaging & Shipping

• Product Dimensions (L×W×H): 326×128×113 mm
• Net Weight: 8.2 kg
• Export Carton Dimensions (mm): 400×360×230
• Products per Carton: 1
• Export Carton Gross Weight: 8 kg

Technical details & installation

• Operating Temperature Range: -20°C to 45°C
• Working Humidity Range: 10%–90% RH
• Mounting: Adjustable bracket mount for aiming and tilt
• Lifespan: 50,000 hours
• Warranty: 5 years
