Multitouch screen panel PC R12FA3S-PCM2AC-POE

touch screenPCAP capacitive touch screen12.1"

Overview
Winmate R12FA3S-PCM2AC-POE is a 12.1-inch HMI Panel PC powered by NXP i.MX6 Dual Core (1.0 GHz), engineered for machine control, factory automation and operator interfaces. It delivers a fanless, low-power platform with front IP65 protection and optional modules (2MP camera, HF RFID) for access control and room information systems.

Key Features

• 12.1" 1024 x 768 display with Projected Capacitive Multi-Touch (PCAP)
• Fanless design and ultra-low power consumption
• PoE support (PD, IEEE 802.3at, 25 W)
• Optional 2 MP front camera
• Optional HF RFID reader (13.56 MHz)
• Built-in RGB LED status light bars (programmable)
• Front IP65 for dust and splash protection

Power over Ethernet (PoE)
PoE consolidates data and power over a single cable, simplifying installation and enabling centralized power management. This makes the panel suitable for access control, industrial automation and installations where cabling and power centralization are priorities.

Design and Ergonomics
The S-series panel is approximately 35% thinner than traditional units and features a true-flat front surface for improved aesthetics and easier cleaning and maintenance in industrial environments.

P-Cap Touch
Projected Capacitive multi-touch supports 4-point touch, offers finger-friendly operation and benefits from a glass cover lens that improves scratch resistance and durability.

LED Light Bar and HF RFID/NFC
Built-in RGB LED status bars on both sides provide visual status indication from a distance. Optional HF RFID/NFC enables restricted access control and user identification functions.

Front IP65
The front bezel is sealed to IP65, protecting the display and touch area from dust ingress and water splashes for reliable operation in typical industrial settings.

Certifications

• CE
• FCC

Technical specifications

• Model: R12FA3S-PCM2AC-POE
• Display: 12.1 inches, 1024 x 768, 500 nits, 1000:1 contrast, active area 245.76 x 184.32 mm
• Touch / Glass: Projected Capacitive Multi Touch (4-point), glass cover
• Processor: NXP i.MX6 Dual Core 1.0 GHz
• Memory: 1 GB (default); 2 GB (optional)
• Storage: eMMC 16 GB (default); eMMC 32 GB (optional)
• OS (optional): Linux Ubuntu 18.04, Android 6.0, Debian 7.0, Linux 4.1.15 QT 5.5
• Wireless: WLAN / Bluetooth (optional)
• RFID: HF RFID 13.56 MHz (optional)
• Light Bar: Built-in RGB LED status bar on both sides
• Dimensions: 296 x 227 x 46 mm; Cut out: 282 x 207 mm; Weight: 3.0 kg
• Mounting: Panel mount (default); VESA mount (optional)
• Enclosure: Metal housing; Cooling: Fanless
• Operating humidity: 10%–90% RH non-condensing; Operating temperature: 0°C to 50°C; Storage temperature: -10°C to 60°C
• IP rating: Front IP65
• IO Ports: 1 x Console (Mini USB), 1 x USB OTG, 1 x USB 2.0 Type-A, 1 x RS232/422/485 (default RS232), 1 x RJ45 LAN with PoE (PD, IEEE 802.3at), 1 x Micro HDMI (optional), 1 x Speaker, 1 x Micro SD slot, 1 x mPCIe slot, 1 x CANBUS D-sub9
• Power: 1 x 12V DC terminal block; Adapter: 12V 50W included; PoE PD follows IEEE 802.3at (25 W)
• Accessories: 100~240V AC to DC adapter, power cord, terminal block to 2.5Ø female adapter, open wire cable with terminal block, VESA screws; Optional: VESA desk stand (9B0000000412)
