Electric Vacuum Glass Lifter with 90° Tilting – AEVGLP8-800
The Aardwolf AEVGLP8-800 Electric Vacuum Glass Lifter is designed for lifting, tilting and positioning large glass sheets in glazing, construction and glass processing applications. Its powered tilting mechanism allows glass panels to move between horizontal and vertical positions through 90°.
The lifter features eight 300 mm vacuum pads mounted on adjustable crossbars and longitudinal beams, allowing the suction pad layout to accommodate different glass sizes. An electric control cabinet, ON/OFF slide valve, audio-visual alarm and automatic vacuum pump restart provide convenient operation and vacuum monitoring.
Key specifications:
• Working load limit: 800 kg horizontal; 400 kg vertical
• Tilting range: 0°–90°
• Vacuum pads: 8 × Ø300 mm
• Glass size range: 2,400 × 800 to 3,600 × 1,800 mm
• Crossbar adjustment: 400 mm per side
• Longitudinal beam adjustment: 250 mm per side
• Power supply: AC 380V, 3-phase, 50/60Hz
• Vacuum flow rate: 4.1/4.7 m³/h
• Net weight: 203 kg
Suitable for large glass panel handling, glazing installation and industrial glass processing, subject to the specified load limits for each lifting orientation.
