Resistive touch screen panel PC R17IAD7T-PMM1

LCD17"Intel® Core™ i9-12900TE

Overview
Winmate R17IAD7T-PMM1 is a 17-inch panel-mount Panel PC powered by Intel® Core™ i9/i7/i5/i3 (Alder Lake / Raptor Lake options). It is built for machine control, factory automation and operator HMI use, offering flexible I/O, expandable storage and long lifecycle availability for industrial deployments.

Key Features

• 17" panel mount Panel PC, 1280 x 1024 resolution
• Intel® Core™ Alder Lake / Raptor Lake family (i3 / i5 / i7 / i9 options)
• 2 x SO-DIMM DDR5 4800MHz, up to 64GB (32GB per slot)
• Integrated dual 2.5 Gigabit Ethernet
• Multi-display: DP 1.4a (default) and optional HDMI 2.0b
• Multiple I/Os: 4 x USB 3.2 Gen2 Type-A, serial ports
• 12V DC power input (Din4 pin connector)

Product Highlights / Design & Usage
High-performance industrial Panel PC designed for continuous operation and system integration. Supports resistive touch or optional protection glass (non-touch). Engineered for efficient thermal management, low power consumption and modular expansion (M.2, SATA, optional WLAN). Standard panel-mount installation with optional VESA mounting for alternative setups.

Certifications

• CE
• FCC

Display

• Size: 17.0 inches
• Resolution: 1280 x 1024
• Brightness: 350 nits
• Contrast Ratio: 1000:1
• Viewing Angles: 85/85/80/80
• Active Area: 337.920 x 270.336 mm
• Touch / Glass: Resistive touch optional; protection glass optional

System Specification

• Processor: Intel® Core™ i3-12100TE default; optional i5-12500TE, i7-12700TE, i9-12900TE; also lists i3-14100T, i5-14500T, i7-14700T, i9-14900T as options
• Chipset: Intel® R680E
• Memory: 2 x non-ECC SO-DIMM, DDR5 4800MHz, up to 64GB
• Storage: 128GB SSD default; optional 256GB/512GB/1TB/2TB/4TB; optional 2 x SATA III for 2.5" drives with RAID support
• Ethernet: 2 x Intel® 2.5 Gbps controllers
• Security: TPM 2.0
• OS (optional): Windows 11 IoT Enterprise 64-bit, Windows 11 Pro 64-bit, Linux Ubuntu 22.04 (Wake on Touch not supported)
• WLAN / Bluetooth: optional (M.2 2230 E-Key)

IO Ports & Expansion

• USB: 4 x USB 3.2 Gen2x1 (10 Gbps, Type A)
• Serial: 1 x RS232/422/485 (default RS232), 1 x RS232
• LAN: 2 x 2.5 Giga LAN RJ45
• Video: 1 x DP1.4a (DP++), up to 4096x2160@60Hz (default); 1 x HDMI 2.0b optional, up to 4096x2160@60Hz
• Audio: Mic-in, Line-out
• Expansion: 1 x M.2 2280 M-Key (NVMe); 1 x M.2 2230 E-Key (Wi‑Fi)
• Power Input: 1 x 12V DC Din4 pin connector

Mechanical

• Dimension: 440 x 360 x 90 mm
• Cut out: 394 x 314 mm
• Weight: 5.9 kg
• Mounting: Panel mount default; VESA optional
• Enclosure: Metal housing
• Cooling System: Fan design

Environment

• Operating Humidity: 10% to 90% RH, non-condensing
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -10°C to 60°C

Buttons & Controls

• 1 x Power Button
• 1 x Reset Button

Accessories

• 100~240V AC to DC adapter
• Power cord
• VESA screws (if applicable)
• Mounting clips

Technical Specifications

• Model: R17IAD7T-PMM1
• Brand: Winmate
• Display: 17.0" / 1280 x 1024 / 350 nits
• CPU: Intel® Core™ i3/i5/i7/i9 (Alder Lake / Raptor Lake options)
• Chipset: Intel® R680E
• Memory: 2 x DDR5 SO-DIMM up to 64GB
• Storage Options: NVMe M.2 and SATA III options up to multiple TB
• Ethernet: Dual 2.5 Gbps Intel® controllers
• USB: 4 x USB 3.2 Gen2 Type-A
• Serial: RS232/422/485 + RS232
• Video Outputs: DP1.4a default, HDMI 2.0b optional
• Power Input: 12V DC (Din4)
• Dimensions / Weight: 440 x 360 x 90 mm / 5.9 kg
• Mounting: Panel mount default; VESA optional
• Operating Temp / Humidity: 0°C to 50°C / 10% to 90% RH
• Certifications: CE, FCC
