Resistive touch screen panel PC R19IAD7T-PMA1

19"Intel® Core™ i9-12900TEIntel® Core™ i7-12700TE

Overview
The R19IAD7T-PMA1 is a 19-inch panel-mount industrial Panel PC designed for machine control, factory automation and operator HMI applications. Based on Intel® Alder Lake S processors, it delivers configurable performance, multiple expansion options and long lifecycle availability for industrial and OEM deployments.

Key Features

• 19” 1280 x 1024 display, 400 nits
• 12th/14th Gen Intel® Core™ processors (i3 / i5 / i7 / i9 and T-series options)
• 2 x SO-DIMM DDR5 4800MHz, up to 64GB
• Integrated dual 2.5 Gigabit Ethernet
• Multi-display: DP 1.4a (default), HDMI 2.0b (optional)
• Multiple I/Os including 4 x USB 3.2 Gen2 (Type-A) and serial ports
• 12V DC power input (Din4 pin connector)

Product Highlights / Features

• Flexible CPU choices: default Intel® Core™ i3-12100TE up to optional i9-14900T
• Storage options: onboard M.2 NVMe (128GB default) and optional capacities to 4TB; optional 2 x 2.5" SATA (RAID support)
• Security: TPM 2.0 support
• OS options: Windows 11 IoT Enterprise, Windows 11 Pro or Linux Ubuntu 22.04 (Wake on Touch not supported on Linux)
• Surface options: resistive touch or protective glass (non-touch)
• Mounting: panel mount default; VESA mount optional
• Rugged design: metal housing with fan cooling for continuous operation

Certifications

• CE
• FCC

Included / Optional Accessories

• 100~240V AC to DC adapter (12V 220W)
• Power cord
• VESA screws and mounting clips

Technical specifications

• Model: R19IAD7T-PMA1
• Display: 19.0"; Resolution: 1280 x 1024; Brightness: 400 nits; Contrast: 1000:1; Active area: 376.32 x 301.06 mm; View angles: 85/85/80/80
• Touch/Glass: Resistive touch optional; Protection glass optional
• Processor (examples): Intel® Core™ i3-12100TE (default); optional i5-12500TE, i7-12700TE, i9-12900TE; newer T-series options up to i9-14900T
• Chipset: Intel® R680E
• Memory: 2 x non-ECC SO-DIMM DDR5 4800MHz, up to 64GB
• Storage: 128GB SSD default; optional 256GB/512GB/1TB/2TB/4TB; 1 x M.2 2280 M-Key (NVMe); optional 2 x SATA III for 2.5" drives (RAID support)
• Ethernet: 2 x Intel® 2.5 Gigabit LAN (RJ45)
• Video output: 1 x DP1.4a (DP++), optional HDMI 2.0b; DP supports up to 4096x2160@60Hz
• USB: 4 x USB 3.2 Gen2x1 (10 Gbps, Type-A)
• Serial: 1 x RS232/422/485 (default RS232) + 1 x RS232
• Audio: Mic in, Line out
• Expansion: 1 x M.2 2230 E-Key (Wi‑Fi module)
• WLAN/BT: optional via M.2 E-Key
• Security: TPM 2.0
• OS: Windows 11 IoT Enterprise 64-bit / Windows 11 Pro 64-bit / Linux Ubuntu 22.04 (no Wake on Touch with Linux)
• Power input: 1 x 12V DC (Din4 pin); Adapter: 12V 220W
• Mechanical: Dimensions 474 x 384 x 87 mm; Cut-out 431 x 341 mm; Weight approx. 6.9 kg; Enclosure: metal housing; Cooling: fan design
• Environment: Operating humidity 10%–90% RH non-condensing; Operating temp 0°C–50°C; Storage temp -10°C–60°C
