Resistive touch screen panel PC W24IT7T-OFA2

LCD24"Intel® Core™ i5-1135G7

Overview
Winmate W24IT7T-OFA2 is a 24-inch open-frame panel PC powered by Intel® Core™ i5 (Tiger Lake) processors, engineered for machine control, factory automation and operator HMI applications. It provides flexible mounting, industrial-grade I/O and long lifecycle availability for OEMs and system integrators.

Key Features

• 24" Full HD (1920 x 1080) display, 250 nits
• Intel® Core™ Tiger Lake UP3: i5-1135G7 (standard) or i5-1145G7E (vPro option)
• Multi-display support via DP / HDMI / LVDS / eDP
• Rich I/O: serial ports, 4 x USB 3.2, dual Intel® Ethernet (1 x 2.5G)
• 12V single-voltage input, fanless low-power design

Product Highlights

• Optional resistive touch or protection glass for non-touch installations
• Designed for continuous industrial operation with effective heat dissipation
• Mounting options: open frame (default), rear panel and VESA

Display

• Size: 24.0 inches
• Touch / Glass: Resistive touch (optional); Protection glass (optional)
• Resolution: 1920 x 1080
• Brightness: 250 nits; Contrast: 3000:1; Viewing angles: 89/89/89/89
• Active area: 527.04 x 296.46 mm

System Specification

• Processor: Intel® Core™ i5-1135G7 (2.4 GHz, up to 4.2 GHz) or i5-1145G7E (vPro)
• Memory: 2 x non-ECC SO-DIMM, up to 64 GB
• Storage: 128 GB SSD default; optional 256 GB–4 TB; 1 x SATA III for 2.5" drive (optional)
• Ethernet: 2 x Intel® controllers (1 x 2.5G + 1 x Gigabit)
• Security: TPM 2.0; Optional WLAN / Bluetooth (M.2 2230)
• OS: Windows 11 IoT Enterprise / Windows 11 Pro / Ubuntu 22.04 (Wake on Touch not supported)

Mechanical

• Dimensions: 576.4 x 343.6 x 69 mm
• Weight: 6.3 kg
• Enclosure: Metal housing; cooling: fanless
• Mounting: open frame (default); panel mount and VESA optional

Environment

• Operating humidity: 10%–90% RH, non-condensing
• Operating temperature: 0°C to 50°C
• Storage temperature: -10°C to 60°C

Certification

• CE
• FCC

I/O Ports

• USB: 4 x USB 3.2 Gen2x1 (Type-A)
• Serial: 1 x RS232/422/485 (default RS232); 1 x RS232
• LAN: 1 x Gigabit LAN (RJ45); 1 x 2.5 Gigabit LAN (RJ45)
• Video: 1 x DP 1.4 (default); 1 x HDMI 2.0 (optional)
• Audio: Mic in; Line out
• Expansion: M.2 2280 M-Key (NVMe), M.2 2230 E-Key (Wi‑Fi), PCIe 4.0 x16 (x4 signal)
• Indicators / Controls: LED power, LED storage, brightness knob, power & reset buttons
• Power input: 1 x 12V DC (Din4); adapter: 12V 120W

Control

• 1 x Power button; 1 x Reset button

Accessories

• 100–240V AC to 12V DC adapter (12V 120W)
• Power cord; VESA screws

Power

• Power rating: 12V DC input
• Adapter: 12V 120W (accessory)

Technical specifications

• Model: W24IT7T-OFA2
• Display: 24" 1920 x 1080, 250 nits, resistive touch optional
• CPU: Intel® Core™ i5-1135G7 (Tiger Lake); i5-1145G7E optional
• Memory: up to 64 GB (2 x SO-DIMM)
• Storage: 128 GB SSD default; optional capacities; M.2 NVMe support
• I/O: 4 x USB 3.2, serial ports, dual Intel® LAN (1 x 2.5G), DP1.4, optional HDMI2.0
• Power: 12V DC (Din4); adapter 12V 120W
• Mechanical: 576.4 x 343.6 x 69 mm; 6.3 kg; metal housing; fanless
• Operating: 0°C to 50°C; 10%–90% RH
• Certifications: CE, FCC
