Screw compressor SK 45 KSP

airelectricstationary

Product overview
The single-stage screw compressor SK 45 KSP is a floor-standing unit engineered to supply compressed air for demanding industrial installations. It provides three selectable pressure levels (8, 10 and 13 bar) with corresponding capacities of 7.51 / 7.10 / 6.05 m³/min. The unit is driven by a 45 kW motor and features a G 1 1/2" connection for integration into compressed air systems.

SK 45 KSP — sturdy industrial design
The model is built for continuous, heavy-duty operation in industrial environments. Two sets of dimensional data are provided in documentation: 1500 × 1030 × 1280 mm (value referenced in text) and table dimensions: length 1585 mm, width 1086 mm, height 1294 mm. Weight: 690 kg. Noise level: 70 dB(A).

Technical data:

• Pressure (bar): 8 / 10 / 13
• Flow (m³/min): 7.51 / 7.10 / 6.05
• Drive power: 45 kW
• Connection: G 1 1/2"
• Noise level: 70 dB(A)
• Weight: 690 kg
• Dimensions (table): L 1585 mm × W 1086 mm × H 1294 mm
• Dimensions (text value): 1500 × 1030 × 1280 mm

Features / specifications

• Type: single-stage screw compressor, floor-standing
• Pressure levels: 8, 10, 13 bar
• Capacity (at 8 / 10 / 13 bar): 7.51 / 7.10 / 6.05 m³/min
• Drive power: 45 kW
• Connection: G 1 1/2"
• Noise level: 70 dB(A)
• Dimensions (table): L 1585 mm, W 1086 mm, H 1294 mm
• Dimensions (text): 1500 × 1030 × 1280 mm
• Weight: 690 kg
