Resistive touch screen panel PC R15IT7T-CHA3WT

15"Intel® Core™ i5-1135G71024 x 768

Overview Winmate R15IT7T-CHA3WT is a 15-inch chassis wide-temperature panel PC powered by Intel® Core™ i5 (Tiger Lake). It is built for machine control, factory automation and operator HMI in industrial and embedded applications where hardware integration, extended operating temperature and lifecycle availability are required.

Key features

• Intel® Core™ Tiger Lake UP3 i5-1135G7 (without vPro) or i5-1145G7E (with vPro)
• 15.0" display, 1024 x 768 resolution, 500 nits
• Multi display support via DP / HDMI / LVDS / eDP
• Multiple I/O: serial ports, 4 x USB 3.2 Type-A, Gigabit and 2.5GbE LAN
• 12V single-voltage DC power input

Resistive touch / Optional protective glass Available with a resistive touch screen or protection glass (non-touch) to match operator requirements in industrial environments.

Low power consumption Designed for low power use and efficient passive heat dissipation suitable for continuous operation in production facilities.

Rear and VESA mounting Supports rear mounting and VESA mounting to fit various installation scenarios and OEM integrations.

Certifications CE, FCC

Technical specifications

• Display - Size: 15.0 inches; Resolution: 1024 x 768; Brightness: 500 nits; Contrast: 2500:1; View angles: 88/88/88/88; Active area: 304.1 x 228.1 mm; Touch/Glass: Resistive touch (optional) or protection glass (optional)
• Processor - Intel Core i5-1135G7 2.4 GHz (up to 4.2 GHz); optional i5-1145G7E with vPro
• Memory - 2 x non-ECC SO-DIMM, up to 64 GB (32 GB per slot)
• Storage - 128 GB SSD (default); optional: 256 GB, 512 GB, 1 TB, 2 TB, 4 TB; 1 x SATA III for 2.5" SSD/HDD (optional); M.2 2280 M-Key (NVMe)
• Ethernet / Networking - 2 x Intel® Ethernet controllers: 1 x Gigabit RJ45 + 1 x 2.5 Gigabit RJ45; M.2 2230 E-Key for Wi‑Fi module (optional); Bluetooth optional
• Security - TPM 2.0
• Operating systems - Windows 11 IoT Enterprise (64-bit) optional; Windows 11 Pro (64-bit) optional; Linux Ubuntu 22.04 (optional, Wake on Touch not supported)
• I/O Ports - 4 x USB 3.2 Gen (Type-A); Serial: 1 x RS232/422/485 (default RS232) + 1 x RS232; Video: 1 x DP1.4 (default), 1 x HDMI 2.0 (optional); Audio: Mic-in, Line-out; Expansion: 1 x PCIe 4.0 x16 slot (x4 signal)
• Indicators & Controls - LED for power; LED for storage; brightness adjustment knob; power and reset buttons
• Mechanical - Dimensions: 360 x 290 x 70 mm; Weight: 4.2 kg; Enclosure: Metal housing; Cooling: Fanless design; Mounting: VESA mount
• Environment - Operating humidity: 30%–90% RH non-condensing; Operating temperature: -20°C to 60°C; Storage temperature: -25°C to 65°C
• Power - Input: 1 x 12V DC (Din4 pin); Adapter: 12V 120W (accessory)
• Accessories - 100~240V AC to DC adapter, power cord, VESA screws
