Resistive touch screen panel PC W24IAD7T-CHA2

LED backlight24"Intel® Core™ i9-12900TE

Overview
Winmate W24IAD7T-CHA2 is a 24-inch chassis panel PC powered by 12th/14th Gen Intel® Core™ processors (Alder Lake S and newer T variants). It is designed for machine control, factory automation and operator HMI applications, providing a metal enclosure, flexible mounting options and long lifecycle availability.

Applications

• Machine control and PLC interfaces
• Factory automation stations and supervisory HMI
• Operator consoles and embedded control systems

Key features

• 24-inch 1920 x 1080 display
• 12th/14th Gen Intel® Core™ options: i3 / i5 / i7 / i9 (Alder Lake S / T variants)
• 2 x SO-DIMM DDR5 4800MHz, up to 64 GB
• Dual integrated 2.5 Gigabit Ethernet
• Multi-display support: DP 1.4a (DP++), HDMI 2.0b optional
• Multiple I/O: 4 x USB 3.2 Gen2x1, serial ports, audio, M.2 expansion
• 12 V DC power input (DIN4)

Highlights

• Optional resistive touch panel or protection glass (no-touch)
• Efficient fan-based cooling and low power design
• Versatile mounting: rear mounting and VESA support
• Security and management: TPM 2.0; configurable OS options

Certifications

• CE
• FCC

Technical specifications

• Model: W24IAD7T-CHA2
• Display: 24.0 inches, 1920 x 1080, 250 nits, 3000:1 contrast, active area 527.04 x 296.46 mm
• Touch / Glass: Resistive touch (optional); protection glass (optional)
• CPU (options): Intel® Core™ i3-12100TE (default); i5-12500TE; i7-12700TE; i9-12900TE; later T-series options available
• Chipset: Intel® R680E
• Memory: 2 x non-ECC SO-DIMM DDR5 4800MHz, up to 64 GB
• Storage: 128 GB SSD default; optional 256/512 GB /1/2/4 TB; optional 2 x SATA III for 2.5" drives (RAID support)
• Ethernet: 2 x Intel® 2.5G LAN RJ45
• Security: TPM 2.0
• OS (optional): Windows 11 IoT Enterprise 64-bit, Windows 11 Pro 64-bit, Linux Ubuntu 22.04 (Wake on Touch not supported on Ubuntu)
• Wireless: WLAN / Bluetooth optional (M.2 2230 E-Key)
• USB: 4 x USB 3.2 Gen2x1 (10 Gbps, Type A)
• Serial: 1 x RS232/422/485 (configurable, default RS232) + 1 x RS232
• Video: 1 x DP1.4a (DP++), up to 4096 x 2160 @60Hz; 1 x HDMI 2.0b optional
• Expansion: 1 x M.2 2280 M-Key (NVMe); 1 x M.2 2230 E-Key (Wi‑Fi)
• Power: 1 x 12V DC DIN4 connector; optional 12V 220W adapter
• Controls: Power and Reset buttons
• Mechanical: 561 x 328 x 84 mm; weight 7.4 kg; metal housing; fan cooling
• Environment: Operating 0°C to 50°C; storage -10°C to 60°C; humidity 10% to 90% RH non-condensing
• Certifications: CE, FCC

Ordering & options
Configurable CPU, memory, storage, OS and wireless modules; accessories include AC/DC adapter, power cord and VESA screws.
