Plastic cable gland HYPAF
metricfor photovoltaic modules

Plastic cable gland - HYPAF - ISC PLASTIC PARTS - metric / for photovoltaic modules
Plastic cable gland - HYPAF - ISC PLASTIC PARTS - metric / for photovoltaic modules
Plastic cable gland - HYPAF - ISC PLASTIC PARTS - metric / for photovoltaic modules - image - 2
Add to favorites
Compare this product

Characteristics

Material
plastic
Other characteristics
metric, for photovoltaic modules
Cable diameter

Max.: 53 mm
(2.09 in)

Min.: 9 mm
(0.35 in)

Description

Product description
Our cross-cut membrane cable glands provide protected cable entry for cables routed through metal panels. Installation is quick and simple. Available materials: PVC and TPE. Measures expressed in: Millimeters.

Materials and compliance
  • PVC and TPE variants (flammability: UL94-HB)
  • RoHS: compliant
  • IP protection: not specified


Measurements and documentation
Measures expressed in: Millimeters
Drawing PDF: available
Video: available

Variants table
Reference | Hole size | Panel thickness | d | H | D1 | D2
02001000507 | 15,00 | 2,00 | 9,00 | 7,00 | 20,00 | 18,00
02001000520 | 18,00 | 2,00 | 11,00 | 7,00 | 22,50 | 21,50
02001000521 | 18,50 | 2,00 | 11,00 | 7,00 | 23,00 | 23,00
02001000522 | 20,00 | 2,00 | 13,50 | 7,00 | 24,00 | 24,00
02001000523 | 20,50 | 2,00 | 13,50 | 7,00 | 25,00 | 25,00
02001000524 | 22,00 | 2,00 | 16,00 | 7,40 | 27,50 | 26,00
02001000525 | 22,50 | 2,00 | 16,00 | 7,00 | 27,50 | 27,50
02001000526 | 28,00 | 2,00 | 21,00 | 8,00 | 34,50 | 34,50
02001000527 | 28,00 | 2,00 | 21,00 | 8,00 | 35,00 | 35,00
02001000528 | 36,50 | 2,20 | 29,00 | 9,45 | 43,00 | 43,00
02001000529 | 37,00 | 2,00 | 29,00 | 9,00 | 44,00 | 44,00
02001000530 | 37,00 | 2,20 | 28,00 | 9,60 | 43,50 | 43,50
02001000531 | 46,00 | 2,50 | 35,00 | 10,30 | 52,50 | 52,50
02001000532 | 47,00 | 2,50 | 35,50 | 10,10 | 52,50 | 52,50
02001000533 | 47,00 | 2,50 | 36,00 | 10,00 | 54,00 | 54,00
02001000534 | 59,00 | 2,50 | 46,50 | 10,50 | 66,20 | 66,20
02001000535 | 59,00 | 2,50 | 47,00 | 10,50 | 67,00 | 67,00
02001000536 | 60,00 | 2,50 | 48,00 | 10,00 | 68,00 | 68,00
02001000537 | 64,00 | 2,50 | 53,00 | 10,00 | 75,00 | 75,00

Technical characteristics / specifications
  • Brand: ISC Plastic Parts
  • Model: HYPAF
  • Type: cross-cut membrane cable gland
  • Materials: PVC, TPE
  • Flammability: UL94-HB (PVC and TPE variants)
  • RoHS: compliant
  • IP protection: not specified
  • Units: dimensions expressed in millimeters
  • Available references and their hole size / panel thickness / dimensions: see variants table above
  • Documentation: drawing PDF available
  • Multimedia: product video available
