Multitouch screen panel PC R15IQ3S-PCC3AC-POE

multi-touch screentouch screenPCAP capacitive touch screen

Overview
Winmate R15IQ3S-PCC3AC-POE is a 15-inch S-Series HMI Panel PC powered by Qualcomm® Snapdragon™ 660 (Octa‑Core 2.2 GHz). Designed for machine control, factory automation and operator HMI applications, it features fanless cooling, ultra‑low power consumption, front IP65 protection, built‑in RGB LED status light bar and optional front camera and HF RFID reader. PoE support simplifies installation by combining data and power on a single cable.

Key Features

• 15" 1024 x 768 TFT LCD with projected capacitive multi-touch (PCAP)
• Fanless design and ultra-low power consumption
• Power over Ethernet (PoE, PD follows IEEE 802.3at, up to 25 W)
• Optional 2MP front camera
• Optional HF RFID reader (13.56 MHz)
• Front panel protection: IP65
• Built-in RGB LED status light bar on both sides
• Thin flat-front design for easy cleaning and integration

Product highlights
The P‑Cap touch supports up to 4-point multi-touch and is scratch resistant due to the glass cover lens. The programmable RGB LED light bar indicates machine or process status from a distance using four colors (red, green, blue, orange). PoE reduces cabling and enables centralized power management for distributed HMI installations. Optional HF RFID/NFC provides restricted access control for security-sensitive sites.

Certifications

• CE
• FCC

Technical specifications

• Display: 15.0 inches, 1024 x 768, 300 nits, 2000:1 contrast
• Touch / Glass: Projected Capacitive Multi Touch Screen
• Active area: 304.1 x 228.1 mm
• Processor: Qualcomm® Snapdragon™ 660 (Octa‑Core 2.2 GHz)
• Memory: 3 GB LPDDR4
• Storage: eMMC onboard 32 GB
• Operating System: Android 9.0
• Connectivity: LAN PoE (at/af), optional WLAN/Bluetooth
• RFID: HF 13.56 MHz (optional)
• IO: 2 x USB2.0 (Type A), 1 x USB3.0 (Type-C), 1 x RS232/422/485, 1 x Micro HDMI (optional), 2 x speaker, 1 x Micro SD slot
• Dimensions (W×H×D): 363.4 x 277.86 x 44.5 mm — Cut out: 346.5 x 261 mm
• Weight: 3.6 kg
• Mounting: Panel mount; VESA mount
• Enclosure: Metal housing
• Operating temperature: 0 °C to 50 °C — Storage: -20 °C to 60 °C
• Shock & Vibration: MIL‑STD‑810G
• IP rating: Front IP65
• Power: 12V DC terminal block (default), optional 9–36V; Adapter: 12V 50W; PoE PD up to 25 W
• Accessories (examples): 100–240V AC to DC adapter, power cord, terminal block adapter, VESA screws
