Mini-ITX motherboard D3634-S mITX

Intel® Celeron®Intel® Core i3Intel® Core i5

Overview
The Mini-ITX industrial motherboard D3634-S is a compact, industry-grade platform based on the cost-optimized Intel® H310 Express chipset. It supports Intel® Core™ i9/i7/i5/i3 (8th/9th Gen) and Intel® Pentium® / Celeron® processors up to 95 W TDP, includes dual Gigabit LAN, dual-channel LVDS and eDP display interfaces, M.2 SSD and Mini-PCIe expansion, and is qualified for 24/7 operation with an extended operating temperature up to 60 °C.

Key highlights

• cTDP — configurable reduction of CPU TDP for thermal/power management
• Cost-effective Intel® H310 industrial platform
• Dual-channel LVDS and eDP support for industrial displays
• M.2 SSD slot and full-size Mini-PCIe socket for expansion
• Flexible power options: ATX PSU or single 12 V input

Benefits of Kontron motherboards

• Engineered and manufactured in Germany for consistent quality
• Strict lifecycle management and long-term product maintenance
• Comprehensive feature set and integration tools
• Dedicated technical support for industrial projects
• Optimized total cost of ownership for system integrators

Technical data (excerpt)
Processor: Intel® 8th & 9th Gen Core™ i9/i7/i5/i3; Intel® Pentium® / Celeron® series up to 95 W TDP. Chipset: Intel® H310. Memory: 2x DDR4 2666 SO-DIMM, up to 32 GB. Graphics: Intel® UHD Graphics (DirectX 12). Display outputs: DisplayPort 1.2, DVI-D, dual-channel LVDS & eDP.

Characteristics / technical specifications

• Form factor: Mini-ITX 170 x 170 mm
• CPU support: Intel® Core™ 8th/9th Gen, Pentium®/Celeron® up to 95 W
• Chipset: Intel® H310 Express
• Memory: 2x DDR4 SO-DIMM, 2666 MT/s, max 32 GB (dual channel)
• Graphics: Intel® UHD Graphics, DirectX 12
• Video: DP 1.2, DVI-D, LVDS/eDP
• LAN: Intel i219LM & i210AT Gigabit
• Storage: 4x SATA III, M.2 Key-M (2242/2260/2280)
• Expansion: 1x Mini-PCIe, 1x M.2 Key-M, PCIe x16 Gen3
• USB: multiple USB 2.0 and USB 3.1 Gen1 ports and headers
• Serial: RS232 and RS232/422/485 (header)
• Power: ATX 24+4 pin or single 12 V input
• BIOS: AMI Aptio 5.x (UEFI)
• Watchdog: 3-level hardware watchdog
• Operating: 0 °C to 60 °C; 24/7 capable
• Dimensions: 170 x 170 mm
• Certifications: cTÜVus IEC62368-1, CE Class B, FCC-B
