Digital I/O module CP-RIO6-A
serialRS-232USB

Digital I/O module - CP-RIO6-A - Kontron - serial / RS-232 / USB
Digital I/O module - CP-RIO6-A - Kontron - serial / RS-232 / USB
Add to favorites
Compare this product
Go to the Kontron website for more information

Characteristics

Signal type
digital
Interface
RJ45, GbE, USB, serial, RS-232, VGA
Number of inputs/outputs
2 digital inputs
Bus standard
CompactPCI, PICMG
Type
rear transition module, RTM
Size
6U

Description

Product information
The CP-RIO6-A is a 4HP Rear I/O interface designed for CP6002, CP6003, CP6004, CP6005, CP6006 and CP6016 6U CompactPCI processor boards. It implements Kontron's proprietary RTM pinout and provides external connectivity including USB, Ethernet, serial, VGA, USB flash headers and SATA. The CP-RIO6-A216 variant is PICMG 2.16 compliant and routes the two Gigabit Ethernet channels to the backplane.

Key features
  • Form factor: 4HP Rear I/O module for 6U CompactPCI
  • Compatibility: CP6002, CP6003, CP6004, CP6005, CP6006, CP6016
  • RTM: Kontron proprietary RTM pinout
  • Interfaces: USB, VGA, RS232, SATA, USB flash headers, HD-Audio
  • Ethernet options: 2x GbE (RJ45) on rear panel; CP-RIO6-A216 routes GbE to backplane (PICMG2.16)
  • Additional headers: fan control, USB flash


Technical data (summary)
  • Ethernet: 2x Gigabit Ethernet (RJ45) at rear panel; CP-RIO6-A216: Ethernet to backplane (PICMG2.16)
  • Storage: 2x USB flash headers; 4x SATA cable connectors; no local hard disk
  • Serial: 1x RS232 on rear panel plus serial headers
  • Video: VGA SUB-D on rear panel
  • USB: 2x Type-A at rear panel; 2x USB flash headers
  • Audio: High Definition Audio header
  • Misc: Fan control header
  • Environmental: Operating temperature 0–60°C; relative humidity up to 93%
