Chassis-mounted power supply PCMA15 S12

AC/DCsingle-outputUL

Product overview
AC/DC module PCMA15 S12 for chassis mounting. Output: 15.6 W at 12 V. Input ranges: 90–264 VAC or 100–300 VDC.

Features

• Wide input range
• Prepared for Class 1/2
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial equipment
• Available for PCB mounting (PMA) and chassis mounting (PCMA)
• Power supply for electronic and electrical circuits in process measurement and control, laboratory equipment, systems and IT

Approvals / Certifications

• CE
• UL / cUL
• RoHS compliance
• UKCA

Technical specifications

• Power: 15.6 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage U1: 12 V
• Output Current I1: 1.3 A
• Efficiency: ≥75 %
• Mounting Type: Chassis mount
• Dimensions: 111.0 x 52.4 x 24.5 mm
• Weight: 200 g
