Printed circuit board power supply PMAS5 S24-S

AC/DCsingle-outputCE

Product description
AC/DC module PMAS5 S24-S for vertical PCB mounting. Power rating 5 W with a 24 V output. Compact dimensions and wide input range make it suitable for decentralised industrial power supplies and sensitive electronic subsystems.

Features

• Wide input range (AC/DC)
• Extremely compact dimensions
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial applications
• PCB mounting
• Plug-and-play power supply unit for sensitive electrical subsystems

Technical Data PMAS5 S24-S (table)
Power — 5 W
AC Input — 90 - 264 V
DC Input — 100 - 300 V
Output Voltage U1 — 24 V
Output Current I1 — 0,21 A
Efficiency — ≥74 %
Mounting Type — PCB Mount
Dimensions — 42,0 x 30,0 x 18,2 mm
Weight — 50 g

Downloads / Additional material

• Datasheet available (PDF)
• 3D CAD drawing available (STEP)

Certifications

• CE
• UL/cUL
• RoHS compliance
• UKCA

Technical characteristics / specifications

• Power: 5 W
• AC input voltage: 90 - 264 V
• DC input voltage: 100 - 300 V
• Output voltage (U1): 24 V
• Output current (I1): 0,21 A
• Efficiency: ≥74 %
• Mounting type: PCB mount
• Dimensions: 42,0 x 30,0 x 18,2 mm
• Weight: 50 g
