Chassis-mounted power supply PCMAS24 S15

AC/DCCERoHS

Product overview
AC/DC power module PCMAS24 S15 for chassis mounting. Nominal power 24 W with fixed output voltage 15 V. Compact dimensions for installation in control cabinets and industrial enclosures.

Features

• Wide input range (AC 90 - 264 V / DC 100 - 300 V)
• Compact chassis-mount form factor
• Overvoltage category 2

Applications

• Decentralised power supply for industrial automation and control systems
• Available as PCB-mount (PMAS) and chassis-mount (PCMAS) versions
• Powering electronic and electrical circuits in process measuring and control technology, laboratory equipment, systems and IT

Technical data

• Power: 24 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage U1: 15 V
• Output current I1: 1.6 A
• Efficiency: 61 %
• Mounting type: Chassis mount
• Dimensions: 111.0 x 52.4 x 24.5 mm
• Weight: 200 g
• Overvoltage category: 2
