Chassis-mounted power supply PCMN30 S48

AC/DCsingle-outputCE

Product
AC/DC power supply for industrial applications, model PCMN30 S48.

Features

• Wide input range for AC and DC sources
• Galvanic isolation 3.3 kVrms
• High efficiency ≥80%

Applications

• Decentralised power supply for industrial control and automation
• Available for PCB-mounting (PMN) and for chassis mounting (PCMN)
• Plug-and-play power unit for sensitive electrical subsystems

Technical Data PCMN30 S48 (table)
Power: 31.2 W
AC Input: 36 - 60 V
DC Input: 36 - 70 V
Output Voltage U1: 48 V
Output Current I1: 0.65 A
Efficiency: ≥80 %
Mounting Type: Chassis mount
Dimensions: 120.0 x 65.0 x 33.0 mm
Weight: 380 g

Technical specifications

• Power: 31.2 W
• AC input range: 36 - 60 V
• DC input range: 36 - 70 V
• Output voltage (U1): 48 V
• Output current (I1): 0.65 A
• Isolation: 3.3 kVrms
• Efficiency: ≥80 %
• Mounting type: Chassis mount
• Dimensions: 120.0 x 65.0 x 33.0 mm
• Weight: 380 g
