Printed circuit board power supply PMAS24 S48

AC/DCsingle-outputCE

Product overview
AC/DC power module PMAS24 S48 designed for PCB mounting, delivering 24 W output power at 48 V. Compact dimensions and a wide input range make it suitable for decentralized industrial power supply.

Features

• Wide AC and DC input range (AC 90–264 V / DC 100–300 V)
• Compact PCB-mount package (75.55 × 50.05 × 22.5 mm)
• Overvoltage category: 2

Applications

• Decentralized power supply for industrial and automation equipment
• PCB-mounted power source for control and measurement systems
• Suitable for laboratory devices, IT systems and process control electronics

Technical Data PMAS24 S48
Power: 24 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 48 V
Output Current I1: 0.5 A
Efficiency: ≥ 83 %
Mounting Type: PCB mount
Dimensions: 75.55 x 50.05 x 22.5 mm
Weight: 150 g

Specifications

• Power: 24 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 48 V
• Output current: 0.5 A
• Efficiency: ≥ 83 %
• Mounting type: PCB mount
• Dimensions: 75.55 x 50.05 x 22.5 mm
• Weight: 150 g
• Protection / Compliance: CE, UL/cUL, RoHS, UKCA (as shown on product page)
