AC/DC power supply PMA30 D515

dual-outputCERoHS

Product overview
AC/DC power module PMA30 D515 — PCB-mounted dual-output AC/DC power supply providing 30 W total power with regulated outputs of 5 V and 15 V. Designed for decentralized power distribution in industrial equipment and control systems where compact PCB mounting and reliable long-term operation are required.

Features

• Wide AC input range (90–264 V) and DC input option (100–300 V)
• Prepared for Class 1/2 insulation and Overvoltage Category II
• Dual outputs: 5 V (3 A) and 15 V (1 A)
• Efficiency ≥ 74 %
• PCB mounting for compact integration

Applications

• Decentralized power supply for industrial automation and control cabinets
• Powering electronic circuits in process measurement and control technology
• Laboratory equipment, instrumentation and IT systems requiring dual rails

Technical data (summary)
Rated power: 30 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output 1 (U1): 5 V — 3 A
Output 2 (U3): 15 V — 1 A
Efficiency: ≥ 74 %
Mounting type: PCB mount
Dimensions (L x W x H): 90.5 x 65.5 x 33.5 mm
Weight: 340 g

Certifications / compliance

• CE
• cUL/UL (UL/cUL)
• RoHS
• UKCA

Technical specifications

• Rated power: 30 W
• AC input voltage range: 90 – 264 V
• DC input voltage range: 100 – 300 V
• Output 1: 5 V, 3 A
• Output 2: 15 V, 1 A
• Efficiency: ≥ 74 %
• Mounting: PCB mount
• Dimensions (L x W x H): 90.5 x 65.5 x 33.5 mm
• Weight: 340 g
• Prepared for Class 1/2 and Overvoltage Category II
