Chassis-mounted power supply PCMAS15 S24

AC/DCsingle-outputCE

Overview
AC/DC module PCMAS15 S24 — chassis-mount power supply providing 15 W output at 24 V. Suitable for decentralized power distribution in industrial systems, with a compact footprint and chassis mounting option.

Features

• Wide input voltage range
• Compact dimensions for space-constrained installations
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial applications
• Available for PCB-mounting (PMAS) and for chassis mounting (PCMAS)
• Powering electronic and electrical circuits in process control, laboratory equipment, systems and IT

Certifications / Compliance
CE, UL/cUL, RoHS compliance, UKCA

Technical Data (table)
Power: 14.4 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 24 V
Output Current I1: 0.6 A
Efficiency: ≥83 %
Mounting Type: Chassis Mount
Dimensions: 84.0 x 51.0 x 22.0 mm
Weight: 100 g

Technical specifications

• Power: 14.4 W
• AC input range: 90–264 V
• DC input range: 100–300 V
• Output voltage: 24 V (U1)
• Output current: 0.6 A (I1)
• Efficiency: ≥83%
• Mounting: chassis mount (PCMAS)
• Dimensions (L x W x H): 84.0 x 51.0 x 22.0 mm
• Weight: 100 g
• Overvoltage category: 2
• Available variants: PCB-mounting (PMAS) and chassis-mounting (PCMAS)
• Certifications: CE, UL/cUL, RoHS, UKCA
