DIN rail power supply HSA24 S12

AC/DCregulatedsingle-output

Product Overview
The HSA24 S12 is a 24 W AC/DC DIN-rail power supply delivering a regulated 12 V output at up to 2.0 A. Designed for industrial control cabinets, it supports wide AC and DC input ranges and compact DIN-rail mounting.

Features

• Wide input range: AC 90 - 264 V / DC 100 - 300 V
• High efficiency (≥81%)
• Output: 12 V, 2.0 A
• Compact DIN-rail housing: 29.0 x 115.0 x 76.0 mm

Applications

• Powering PLCs, sensors, actuators and HMIs
• Industrial automation and control cabinets
• Field devices requiring DIN-rail mounting

Technical Data (table)

• Power: 24 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage U1: 12 V
• Output Current I1: 2.0 A
• Efficiency: ≥81%
• Mounting Type: DIN Rail Mount
• Dimensions: 29.0 x 115.0 x 76.0 mm
• Weight: 250 g

Certifications

• CE
• UL / cUL
• RoHS compliance
• UKCA

Datasheet
Datasheet (PDF) available.

Specifications

• Power: 24 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage: 12 V
• Output Current: 2.0 A
• Efficiency: ≥81%
• Mounting Type: DIN Rail Mount
• Dimensions: 29.0 x 115.0 x 76.0 mm
• Weight: 250 g
