AC/DC power supply PCMAS24 S05

single-outputCERoHS

Product Overview
AC/DC Module PCMAS24 — reliable, outstanding lifetime, robust, chassis mounting, power 20 W, output voltage 5 V

Features

• Wide Input Range
• Smallest Dimensions
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial applications
• Available for PCB-mounting (PMAS) and for chassis mounting (PCMAS)
• For supplying electronic and electrical circuits in process measuring and control technology, laboratory equipment, systems and information technology

Downloads

• Datasheet (PDF) available
• 3D CAD drawing (STP) available

Certifications

• CE
• UL / cUL
• RoHS
• UKCA

Technical Data (table)
Power: 20 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 5 V
Output Current I1: 4,0 A
Efficiency: ≥79 %
Mounting Type: Chassis Mount
Dimensions: 111,0 x 52,4 x 24,5 mm
Weight: 200 g

Caractéristiques / Spécifications techniques

• Power: 20 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 5 V
• Output current: 4.0 A
• Efficiency: ≥79 %
• Mounting: Chassis Mount
• Dimensions: 111.0 x 52.4 x 24.5 mm
• Weight: 200 g
• Overvoltage category: 2
• Available downloads: Datasheet (PDF), 3D CAD drawing (STP)
• Certifications: CE, UL/cUL, RoHS, UKCA
