Chassis-mounted power supply PCMAS15 S15

AC/DCsingle-outputCE

Overview
Compact AC/DC power module PCMAS15 S15 designed for chassis mounting. Provides 15 W output at 15 V with a wide input range suitable for industrial and process-control environments. Rated Overvoltage Category II.

Features

• Power: 15 W
• Output: 15 V, 1.0 A
• AC input: 90–264 V / DC input: 100–300 V
• Efficiency ≥81 %
• Chassis mounting; dimensions 84.0 x 51.0 x 22.0 mm

Applications

• Decentralised power supply for industrial automation and control systems
• Supply for electronic circuits in process measurement, laboratory equipment and IT systems
• Available variants for PCB mounting (PMAS) and chassis mounting (PCMAS)

Downloads

• Datasheet (PDF)
• 3D CAD drawing (STP)

Technical Data PCMAS15 S15

• Power: 15 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage U1: 15 V
• Output Current I1: 1.0 A
• Efficiency: ≥81 %
• Mounting Type: Chassis mount
• Dimensions (W x D x H): 84.0 x 51.0 x 22.0 mm
• Weight: 100 g

Certifications / Compliance

• CE
• UL / cUL
• RoHS compliant
• UKCA

Technical specifications

• Power: 15 W
• Output voltage: 15 V
• Output current: 1.0 A
• AC input range: 90–264 V
• DC input range: 100–300 V
• Efficiency: ≥81 %
• Mounting: chassis mount
• Dimensions (W x D x H): 84.0 x 51.0 x 22.0 mm
• Weight: 100 g
